ID2000 Series Installation & Commissioning Manual
Appendix 3
A3 - 2997-433-000-5, Issue 5
May 2010
Compatible CLIP Protocol Loop Devices:
Sensors Modules
CPX-551E Standard Ionisation Sensor M500KACGB Manual Call Point
CPX-751E Low Profile Ionisation Sensor M500KACW Weatherproof Manual Call Point
FSL-751E VIEW laser-based smoke sensor M500KACEU EU-style Manual Call Point
LPX-751 VIEW laser-based smoke sensor (low profile) M700KAC-FG Manual Call Point - non-isolated
SDX-751TEM OptiPlex Multi-Sensor M700KACI-FG Manual Call Point - with isolator
SDX-551E Standard Optical Sensor M700X Isolator module
SDX-751XXXX Low Profile Optical Sensor M701 Single output module
FDX-551XXX - Grade 2 Thermal Sensor; M701-240 Output Module 240VAC
- High TemperatureThermal Sensor; M701-240-DIN Output Module 240VAC (DIN mounting)
- Grade 1 Rate of Rise Thermal Sensor M710 Single Input Module
HPX-751E HARSH Optical Sensor M720 Dual Input Module
IRX-751TEM SMART 3 Multi-Criteria Sensor M721 Dual Input, Single Output Module
LPB-500 Loop Powered Beam Detector (TX/RX pair) MCX-55 5-way Relay Card/ 5 inputs
LBP-620 Loop Powered Beam Detector MMX-1E Monitor Module
LPB-700/-700T Loop Powered Beam Detector (<70m) /+ test MMX-101E Mini Monitor Module
IDX-751
1
HAZARD Intrinsically-safe smoke sensor MMX-102E Micro Monitor Module
B524RE Voltage-free Relay Base MMX-10M 10 Way Monitor Module
B524FTXE HARSH Sensor Base M710-CZ Conventional Zone Monitor Module
B524IXXX- Sensor Base With Standard Isolator; ZMX-1 Conventional Zone Monitor Module
- Sensor Base With FET Isolator; CMX-2E Control Module (Monitored or Relay)
- Sensor Base With Relay Output; PS2-701 Control Module With PSU and 2 Bell Circuits
B501 Standard Sensor Base CMX-10RM 10 Way Relay Module
DH500 Duct Detector Housing (indication only) ISO-X Standard Isolator Module
DH500AC/DC Duct Detector Assy for 500 Series detectors ISO524-1 Mini Isolator Module
DH500ACDC-E Duct Detector Housing 24V (c/w relays) MRM-1 Mains Relay Modules
MRM-1DIN Mains Relay Modules - DIN Rail version
ANS4
2
Addressable Loop-powered Sounder
ANSE4
2
Addressable Externally-powered Sounder
ABS4
2
Addressable Loop-powered Sounder Base
ABSE4
2
Addressable Externally-powered Sounder Base
IBS3 Addressable Loop-powered Base Sounder
with Built-in Sensor Base
AWS3
2
Addressable Loop-powered Wall Sounder
AWS32 Addressable Loop-powered Wall Sounder
AWS32-I
2
Addressable Loop-powered Wall Sounder with
isolator.
1
Requires the Y72221 Isolation Unit
2
Colour options available
Some devices may be under development, Contact NOTIFIER regarding device availability
Compatible OPAL Protocol Loop Devices:
Sensors Modules
NFX-OPT Standard Optical Sensor M500KACW Weatherproof Manual Call Point
NFXI-OPT Standard Optical Sensor - with isolator M700KAC-FG Manual Call Point
NFX-SMT2 OptiPlex Multi-Sensor M700KACI-FG Manual Call Point - with isolator
NFXI-SMT2 OptiPlex Multi-Sensor - with isolator M700X Isolator module
NFX-TDIFF Thermal Sensor Type A1R M701 Single output module - with isolator
NFXI-TDIFF Thermal Sensor Type A1R - with isolator M701-CZ Zone monitor module - with isolator
NFX-TFIX58 Thermal Sensor 58°C M701-240 Output Module 240VAC - with isolator
NFXI-TFIX58 Thermal Sensor 58°C - with isolator M710 Single Input Module - with isolator
NFX-TFIX78 Thermal Sensor 78°C M720 Dual Input Module - with isolator
NFXI-TFIX78 Thermal Sensor 78°C - with isolator M721 Dual Input, Single Output Module - with isol.
NFXI-SMT3 SMART 3 Multi-Criteria Sensor AWS32/x Addressable Loop-powered Sounder
AWS32/x-I Addressable Loop-powered Sounder - with isol.
AWSB32/x/R Sounder/strobe
AWSB32/x/R-I Sounder/strobe - with isolator
ABS32/x Sounder base
ABS32/x-I Sounder base - with isolator
AWB/R-I Strobe - with isolator
ABSB32/x/C-I Sounder/Strobe - with isolator
AWB/R Strobe
