14 NFS-320 and NFS-320SYS UL Listing Document — P/N 52745LD:G9 5/19/2022
Zone Map: ZA
Custom Label: Exit Door #
Motion Detectors with Monitor Modules
Address: LXXMYYY (arbitrary)
Type ID: ACCESS MONITOR
Zone Map: ZB
Custom Label: Motion Detection
6. Programming of Logic Equations
Logic Equation for 1 minute exit delay:
ZLa* = DEL(00:30, 00:00:00, address of key switch)
Logic Equation for Trouble arming system:
ZLb* = AND (ZA, address of key switch, NOT(Zla))
Logic Equation to arm system:
ZLc* = AND (ZLa, NOT(ZLb))
Logic Equation providing 30-second entry delay:
ZLd* = SDEL(00:00:30, 00:00:30, AND (ZA,ZLc)
Logic Equation for Security Alarm:
ZLe* = AND (ZLc, OR (ZLd))
*Follow the following restrictions on values:
a < b < c < d <e
7. Programming Group Interfaces
Group Interface for Trouble when system is armed while access point(s) active
A. CM programming
Address:LXXMYYY (arbitrary)
Type ID:RELAY
Zone Map:ZLb
Custom Label:Arming Trouble Group Output
Signal Silence:No
Walk Test:Yes/No (Installer Specified)
Switch Inhibit:Yes
B. MM Programming
Address:LXXMYYY (arbitrary)
Type ID:TROUBLE MON
Zone Map:(none)
Group Interface for Security Alarm
A. CM programming
Address:LXXMYYY (arbitrary)
Type ID:RELAY
Zone Map:ZLe
Custom Label:Security Group Output
Signal Silence:No
Walk Test:Yes/No (Installer Specified)
Switch Inhibit:Yes
B. MM Programming
Address:LXXMYYY (arbitrary)
Type ID:SECURITY-L
Zone Map:(none)
