NFS-320 and NFS-320SYS UL Listing Document — P/N 52745LD:G9 5/19/2022 27
Ion
SMOKE (ION)
(See notes
1
and
3
)
AL:1=0.50 %
AL:2=0.75 %
AL:3=1.00 %
AL:4=1.25 %
AL:5=1.50 %
AL:6=1.75 % (d)
AL:7=2.00 %
AL:8=2.25 %
AL:9=2.50 %
AL:1=0.50 %
AL:2=0.75 %
AL:3=1.00 %
AL:4=1.25 %
AL:5=1.50 %
AL:6=1.75 % (d)
AL:7=2.00 %
AL:8=2.25 %
AL:9=2.50 %
PA:1=Auto
PA:2=0.40 %
PA:3=0.50 %
PA:4=0.75 %
PA:5=1.00 %
PA:6=1.25 % (d)
PA:7=1.50 %
PA:8=1.75 %
PA:9=2.00 %
FlashScan View® Laser
(See Note
4
)
AL:1=0.02 %
AL:2=0.03 %
AL:3=0.05 %
AL:4=0.10 %
AL:5=0.20 %
AL:6=0.50 % (d)
AL:7=1.00 %
AL:8=1.50 %
AL:9=2.00 %
AL:1=0.02%
AL:2=0.03 %
AL:3=0.05 %
AL:4=0.10 %
AL:5=0.20 %
AL:6=0.50 % (d)
AL:7=1.00 %
AL:8=1.50 %
5
AL:9=2.00 %
PA:1=Auto
PA:2=0.02 %
PA:3=0.05 %
PA:4=0.10 %
PA:5=0.20 %
PA:6=0.50 % (d)
PA:7=0.70 %
PA:8=1.00 %
PA:9=1.50 %
Acclimate® Plus™
(See Note
6
and
7
) AL:1=0.50 %
AL:2=1.00 %
AL:3=1.00 to 2.00 %
AL:4=2.00 %
AL:5=2.00 to 3.00% (d)
AL:6=3.00 %
AL:7=3.00 to 4.00 %
AL:8=4.00 %
AL:9=thermal 135
o
F
Alarm (CLIP)
AL:1=1.00 %
AL:2=1.00 %
AL:3=1.00 to 2.00 %
AL:4=2.00 %
AL:5=2.00 to 4.00% (d)
AL:6=2.00 to 4.00%
AL:7=2.00 to 4.00%
AL:8=4.00 %
AL:9=4.00%
PA:1=0.50%
PA:2=1.00 %
PA:3=1.00 %
PA:4=1.00 to 2.00%
PA:5=1.00 to 2.00 % (d)
PA:6=2.00 %
PA:7=2.00 %
PA:8=2.00 to 3.00 %
PA:9=2.00 to 3.00 %
Beam Detector
(See note
8
)
AL:1=25%
AL:2=30%
AL:3=40%
AL:4=50%
AL:5=30 - 50%
AL:6=40 - 50%
AL:1=25%
AL:2=30%
AL:3=40%
AL:4=50%
AL:5=30 - 50%
AL:6=40 - 50%
N/A
FSC-851 IntelliQuad Detector
9
AL:1=1%
AL:2=2%
AL:3=3%
AL:4=3% w/ 10 minute confirmation
10
AL:5=4% w/ 10 minute confirmation
AL:6=Thermal 135
o
F
AL:7=Thermal 135
o
F
AL:8=Thermal 135
o
F
AL:9=Thermal 135
o
F
N/A PA:1=1%
PA:2=1%
PA:3=2%
PA:4=3%
PA:5=3% w/ 10 minute confirmation
PA:6=4% w/ 10 minute confirmation
PA:7=4% w/ 10 minute confirmation
PA:8=4% w/ 10 minute confirmation
PA:9=4% w/ 10 minute confirmation
IntelliQuad PLUS Multi-Criteria Fire/CO
Detector
11
AL:1=1%
AL:2=2%
AL:3=3%
AL:4=3% w/ 10 minute confirmation
10
AL:5=4% w/ 10 minute confirmation
AL:6=Thermal 135
o
F
N/A PA:1=1%
PA:2=1%
PA:3=2%
PA:4=3%w/ 10 minute confirmation
PA:5=3%w/ 10 minute confirmation
PA:6=4% Thermal 135
o
F
1 Detectors are suitable for open area protection within the listed air velocity range. Typically, this range is 0 - 4,000 ft/min for photoelectric detectors and 0 - 1,200 ft/min for
ionization detectors. Be sure to confirm this range before installing the detector by referring to the manufacturer’s installation instructions. The nominal sensitivity displayed
on the FACP is for reference only.
2 FSP-951, FSP-951-IV, FSP-951R, FSP-951R-IV, FSP-951T, FSP-951T-IV detectors must be programmed with sensitivity level 8 or 9 for Open Area Protection, and Levels
1 through 7 for Special Applications to be compliant with UL 268 7th Edition requirements (Default = 8).
3 Use only alarm sensitivity setting of AL=1, AL=2 or AL=3 for ION detectors installed in Canada.
4 The use of alarm sensitivities below 0.50% obscuration per foot requires a 90 day test to ensure that the environment for the detectors is suitable for the higher sensitivity
setting.
5 1% maximum on CLIP. Higher figures may display.
6 For Acclimate detectors installed in Canada: Use only the alarm settings of AL:1 or AL:2.
7 FPTI-951, FPTI-951-IV detectors must be programmed with sensitivity level 8 for Open Area Protection, and Level 2, 4, or 6 (Default=8) for Special Applications to be
compliant with UL 268 7th Edition requirements.
8 Refer to the beam detector manual to determine the alarm settings: they are a function of the distance between the detector and its reflector.
9 In CLIP mode, any AL: settings over AL:5 will be set to AL:5 by the panel. Any PA: settings over PA:5 will be set to PA:5 by the panel.
10 Within the 10 minute fire signature confirmation delay period if there is a detection of another fire signature (Carbon Monoxide, Infrared or Thermal) it overrides the 10
minute confirmation time.
11 FCO-951, FCO-951-IV detectors must be programmed with sensitivity level 3, 4, or 5 for Open Area Protection, and Level 1 or 2 (Default = 4) for Special Applications to be
compliant with UL 268 7th Edition requirements.
Type Code
Point Characteristics
Device Function
Point Type
Latching
(Y/N)
Point Function
SMOKE (ION) fire alarm Y lights fire alarm LED and activates CBE Ionization smoke detector
SMOKE(DUCTI) fire alarm Y lights fire alarm LED and activates CBE Duct Ionization smoke detector
SUP.T(DUCTI)
1
supervisory N lights supervisory LED Ionization smoke detector used as a duct detector to
report supervisory condition rather than alarm.
Tracking.
Table 7 Intelligent Detector Type Codes (1 of 3)
Detector Type Alarm (FlashScan) Alarm (CLIP) Pre-Alarm
Table 6 Detector Sensitivity (in percent obscuration per foot) (2 of 2)
