30 NFS-320 and NFS-320SYS UL Listing Document — P/N 52745LD:G9 5/19/2022
Type Code
Point Characteristics
Device Function
Point Type
Latching
(Y/N)
Point Function
MONITOR fire alarm Y Lights fire alarm LED and activates CBE Alarm-monitoring device
PULL STATION fire alarm Y Lights fire alarm LED and activates CBE Manual fire-alarm-activating device, such as a pull station
RF MON MODUL fire alarm Y Lights fire alarm LED and activates CBE Wireless alarm-monitoring device
RF PULL STA fire alarm Y Lights fire alarm LED and activates CBE Wireless manual fire-alarm-activating device, such as a pull
station
SMOKE CONVEN fire alarm Y Lights fire alarm LED and activates CBE Indicates activation of a conventional smoke detector
attached to an FZM-1
SMOKE DETECT fire alarm Y Lights fire alarm LED and activates CBE Indicates activation of a conventional smoke detector
attached to an FZM-1
WATERFLOW fire alarm Y Lights fire alarm LED and activates CBE Monitor for waterflow alarm switch
WATERFLOW S supervisory Y Lights supervisory LED and activates CBE Indicates supervisory condition for activated waterflow
switch
ACCESS MONTR non-alarm N Activates CBE Used for monitoring building access
AREA MONITOR security Y Lights security LED and activates CBE Monitors building access
AUDIO SYSTEM trouble N Lights trouble LED Not used
EQUIP MONITR security N Activates CBE Used for recording access to monitored equipment
RF SUPERVSRY supervisory N Lights Supervisory LED Monitors a radio frequency device
SECURITY security Y Lights security LED Indicates activation of security alarm
LATCH SUPERV supervisory Y Lights supervisory LED Indicates latching supervisory condition
TRACK SUPERV supervisory N Lights supervisory LED Monitors for waterflow tamper switches for alarm points
SYS MONITOR security Y Lights security LED and activates CBE Monitors equipment security
TAMPER supervisory Y Lights supervisory LED, activates CBE Indicates activation of tamper switch
ACK SWITCH non-alarm N Performs Acknowledge function, no CBE Silences panel sounder, gives an Acknowledge message
on the panel LCD
ALLCALL PAGE non-alarm N Activates all speaker circuits, no CBE Not used
DRILL SWITCH
1
non-alarm N Performs Drill function Activates silenceable outputs
EVACUATE
SWITCH
2
non-alarm N Performs Drill function Activates all silenceable outputs
FIRE CONTROL non-alarm Y Activates CBE Used for non-fire activation of outputs
NON FIRE non-alarm N Activates CBE Used for building energy management
PAS INHIBIT
3
non-alarm N Inhibits Positive Alarm Sequence Inhibits Positive Alarm Sequence
POWER MONITR trouble N Indicates trouble Monitors auxiliary power supplies
RESET SWITCH non-alarm N Performs Reset function Resets control panel
SIL SWITCH non alarm N Performs Signal Silence function Turns off all activated silenceable outputs
TELE PAGE non-alarm N Performs function of Page Button on FFT-7 Not used
DISABLE MON disable N When a point with this type code activates, it
will create a disable on the panel for that
point. No CBE generated.
Module can not be disabled via ACS, Alter Status, or over
the network.
TROUBLE MON trouble N Indicates Trouble Monitors trouble inputs
ABORT SWITCH non alarm N Indicates Active at the panel Aborts activation of a releasing zone.
Note: Abort switch can only be associated with one (1)
releasing zone.
MAN RELEASE fire alarm Y Lights Fire Alarm LED and activates CBE Indicates activation of a monitor module programmed to
releasing zone to perform a releasing function
MANREL DELAY fire alarm Y Lights Fire Alarm LED and activates CBE Indicates activation of a monitor module programmed for a
release output
SECOND SHOT fire alarm Y Indicates Active at the panel and activates
CBE
Provides second activation of releasing zone after soak
timer has expired.
Blank fire alarm Y Lights fire alarm LED and activates CBE Monitors for a device with no description
HEAT DETECT fire alarm Y Lights fire alarm LED and activates CBE Monitors for conventional heat detector
CO MON
4
CO alarm Y Activates CBE, no LED will light for CO alarm Monitors conventional CO detector
ECS/MN SUPT supervisory N Lights supervisory LED and activates CBE. Monitors mass notification devices.
ECS/MN SUPL supervisory Y Lights supervisory LED and activates CBE. Monitors mass notification devices
Table 8 Monitor Module Type Codes (1 of 2)
Default zone
Blinking Type Code selection
CBE list
(five zones)
12 spaces for extended
custom label
SLC number (1 or 2)
M (module)
SLC address (001-159)
PROGRAM MONITOR WESTERN ENTRANCE AND
HALLWAY 09 __ __ __ __ 1M101
20-character user-editable custom label.
