NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022 39
When programming an ACS point with a mode of Control, the following Control Point Select screen will be displayed:
Control Source field entry formats may be:
• SLC Modules
: NxxxLyyMzzz.
xxx = FACP node number
yy - the SLC loop number
zzz - module loop address
• General Zones
*: NxxxZyyy.
xxx = FACP node number
yyy = General zone number (Z001 - Z999, not Z000. Zone 0 is not valid).
• Panel Circuit Modules: NxxxPyy.z.
xxx = FACP node number
yy = panel circuit module number
z = panel circuit push button number
• Prioritized Audio Matrix (PAM) Speaker Points
: NxxxIyyyyAzzSn xxx =
the DVC node number
yyyy = the input number in the PAM
zz = the DAA address on the Digital Audio Loop (01 through 32)
n = the DAA speaker circuit (1 through 4).
*DO NOT MIX GENERAL ZONES WITH OTHER SOURCE TYPES FOR AN ACS CONTROL POINT. Program up to eight general zones or up
to eight other control point types.
PAGE
INACTIVE
...will, when pressed after a Page Enable, allow PAGE
INACTIVE paging from that source. The Special Paging
Function map programming at the DVC will receive the page
function.
The Point Active LED is lit if a corresponding mapped point is
active. The Status (trouble) LED is on when a point or zone is in
trouble.
PAGE EVAC ...will, when pressed after a Page Enable, allow Page Evac
paging from that source. The Special Paging Function map
programming at the DVC will receive the page function.
The Point Active LED is lit if a corresponding mapped point is
active. The Status (trouble) LED is on when a point or zone is in
trouble.
PAGE ALERT ...will, when pressed after a Page Enable, allow Page Alert
paging from that source. The Special Paging Function map
programming at the DVC will receive the page function.
The Point Active LED is lit if a corresponding mapped point is
active. The Status (trouble) LED is on when a point or zone is in
trouble.
FFT-NFN ....will, when pressed:
• Notify a DVC in the map format Nxxx,Nxxx,NxxxLyyMzzz or
Nxxx,Nxxx,NxxxAyyT to open the FFT-NFN link and turn on
the mapped FFT point or riser. A second press will notify the
DVC to turn off that FFT point or riser and determine whether
the FFT-NFN link should be closed or remain open.
• Notify a DVC in the map format Nxxx,Nxxx to close or open
the FFT-NFN link between two DVCs.
The Point Active LED is lit if a corresponding mapped point is
active. The Status (trouble) LED is on when a point or zone is in
trouble.
CO MONITOR … will show the current state of the CO element for the
specified point entered.
The Point Active LED is lit if a corresponding mapped point is
active. The Status (trouble) LED is on when a point is in trouble.
This point is specifically used to annunciate the CO element of the
FIRE/CO detector.
CAUTION: DISABLED/ENABLED OUTPUTS
WHEN A DISABLED OUTPUT IS ENABLED, IT WILL BE AFFECTED BY CONDITIONS PRE-EXISTING IN THE SYSTEM.
FOR EXAMPLE, WHEN A CONDITION EXISTS IN THE SYSTEM THAT WOULD NORMALLY TURN THE OUTPUT ON,
THE OUTPUT WILL TURN ON WHEN IT IS ENABLED.
NOTE: A zone with a node number of zero (0) will be a local zone.
ACS Point Mode Function: The point… Explanation
Table 3 ACS Point Mapping: Explanation of Point Modes (2 of 2)
Control Point Select Screen
CONTROL POINT SELECT
N000I0001A00S1 xxx
xxx xxx
xxx xxx
xxx xxx
