40 NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022
Supervision
Selecting the Supervision option on the first Panel Programming screen will display the following programming options:
MAIN POWER SUPPLY AC FAIL ADDRESS : Press to enter the “Monitor AC
Fail” (base plus one) address of the main power supply. Refer to the main power
supply manual for complete addressing information. The LCD backlight will
turn off when this power supply experiences AC failure (see BACKLIGHT in,
"LCD Programming" on page 37).
PRINTER: Press to scroll through the types of printer supervision: NONE, 40-
COLUMN, 40-COLUMN SUPERVISED, 80-COLUMN, 80-COLUMN SUPER-
VISED, 40 GRAPHIC, 80 GRAPHIC, 80 GRAPHIC SUPERVISED. The
printer will not be active if
NONE is selected. If a SUPERVISED selection is made,
the printer will be supervised. Default: None.
CRT BAUD RATE: Press to scroll through CRT baud rates. “SUP” after the rate indicates supervised. Select from: 4800, 4800 SUP, 9600,
9600 SUP, 19200, 19200 SUP, 38400, 38400 SUP, 57600, 57600 SUP. Default: None.
AUXILIARY TROUBLE REPORTING: Toggle between YES and NO. Choose Yes if a trouble bus cable has been attached at J5 of the CPU2-3030
(CPU2-3030DC for Canada only) . Default: NO
TAMPER INPUT: Toggle between YES, NO, and AKS-1. Choosing Yes reports a tamper situation at the panel cabinet door determined by an STS-1
tamper switch connected. Choosing No does not report a tamper situation at the panel cabinet door determined by an STS-1 tamper switch connected.
AKS-1 should be selected when there is an AKS-1 key switch connected to the panel cabinet door (which allows the operator to use Signal Silence,
Reset, Drill (Alarm Signal on for Canadian applications) and Acknowledge functions when a key turns the lock to “Enable”). Default: NO
MORE: Press to display the second Supervision screen.
TERMINAL: Select NONE or LCD-80. (Default: None.) When LCD-80 is
selected, LCD-160/C programming is not allowed.
Password Change
Selecting the Password Change option on the second Panel Program Menu will display the Change Password screen.
The NFS2-3030 has two password levels; master and user. There is one master
password, which grants access to all system programming. There are nine user
passwords, each of which may be assigned access to the programming change
menus, the alter status menus, or both. A user password does not give access to
or allow change to any password parameters, not even its own. Only the master
password will allow access to password change screens.
The panel arrives with factory default settings of 00000000 for the master pass-
word, and 11111111 for one user password.
NOTE: When changing from an 80-column or 80-column supervised to
an 80 graphic or 80 graphic supervised printer (or vice-versa), settings
must be changed at the printer.
NOTE: When LCD-80 Terminal Supervision is on (LCD-80 is selected at the More Supervision screen), CRT baud rate selections of 19200
and 57600 are unavailable.
NOTE: When LCD-80 Terminal Supervision is enabled, CRT baud rate
selections of 19200 and 57600 are unavailable.
NOTE: Only a master password user can change another password.
Supervision Screen (1)
SUPERVISION
MAIN PS AC FAIL ADDRESS: LXXMXXX
PRINTER: 80-COLUMN
CRT BAUD RATE: 57600 MORE
AUXILIARY TROUBLE REPORTING:NO ACCEPT
TAMPER INPUT: NO BACK
Supervision Screen (2)
SUPERVISION
TERMINAL:LCD-80 ACCEPT
BACK
Change Password Screen
CHANGE PASSWORD
MASTER PASSWORD
USER PASSWORD
BACK
