NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022 61
ACS Board Label
Selecting an ACS Board in the Point Select of the Point Programming screen will display ACS Label Menu:
ACS LABEL: Type a label for the selected annunciator. The label can have up
to 40 characters.
TROUBLE REPORTING DELAY: Smoke Control Systems only: Adjustable
trouble timer for FSCS. Programmable range is 0 to 180 seconds. Default: 90.
PAIRING: Smoke Control Systems only: Select group 1, 2 or 3 to pair up to
eight (8) FSCS boards so that multiple smoke control modules can act as a sin-
gle unit. If enabled, each FSCS address can only be assigned to one group and
each group can be assigned up to eight (8) FSCS addresses. Default: X
PAIRED FSCS: Smoke Control Systems only: Displays any FSCS boards that
have been paired to this annunciator.
MORE: Smoke Control Systems only: Press to display the second ACS label screen.
To assign a label to a switch group, modify the zone’s label via Point Programming (refer to page 43) and assign that zone to the desired switch group.
ZONE SELECTION: Press to assign the zone label that is to be displayed for
the switch group selected.
VIEW: Press to view the associated zone label for the switch group selected.
UP/DOWN: Press to move between switch group selections.
MORE: Press to display the third ACS label screen.
619 PRIMARY AMP 4
HARDWARE FAILURE
620 BACKUP AMP 1 HARDWARE
FAILURE
621 BACKUP AMP 2 HARDWARE
FAILURE
622 BACKUP AMP 3 HARDWARE
FAILURE
623 BACKUP AMP 4
HARDWARE FAILURE
624 DSBUS 1 COMMFAIL 625 DSBUS 2 COMMFAIL 626 DSBUS 3 COMMFAIL
627 DSBUS 4 COMMFAIL 628 AA TROUBLE BUS FAIL 629 NFN PAGING CHANNEL
LIMIT EXCEEDED
630 BACKUP AMP LIMIT
631 PRIMARY AMP 1 LIMIT 632 PRIMARY AMP 2 LIMIT 633 PRIMARY AMP 3 LIMIT 634 PRIMARY AMP 4 LIMIT
635 BACKUP AMP 1 LIMIT 636 BACKUP AMP 2 LIMIT 637 BACKUP AMP 3 LIMIT 638 BACKUP AMP 4 LIMIT
639 PRIMARY AMP 1
OVERCURRENT
640 PRIMARY AMP 2
OVERCURRENT
641 PRIMARY AMP 3
OVERCURRENT
642 PRIMARY AMP 4
OVERCURRENT
643 BACKUP AMP 1
OVERCURRENT
644 BACKUP AMP 2
OVERCURRENT
645 BACKUP AMP 3
OVERCURRENT
646 BACKUP AMP 4
OVERCURRENT
647 PRIMARY AMP 1 TRIP 648 PRIMARY AMP 2 TRIP 649 PRIMARY AMP 3 TRIP 650 PRIMARY AMP 4 TRIP
651 BACKUP AMP 1 TRIP 652 BACKUP AMP 2 TRIP 653 BACKUP AMP 3 TRIP 654 BACKUP AMP 4 TRIP
655 DSBUS 1 AC FAIL 656 DSBUS 2 AC FAIL 657 DSBUS 3 AC FAIL 658 DSBUS 4 AC FAIL
659 DSBUS 1 HIGH BATT 660 DSBUS 2 HIGH BATT 661 DSBUS 3 HIGH BATT 662 DSBUS 4 HIGH BATT
663 DSBUS 1 LOW BATT 664 DSBUS 2 LOW BATT 665 DSBUS 3 LOW BATT 666 DSBUS 4 LOW BATT
667 DSBUS 1 SELF TEST FAIL 668 DSBUS 2 SELF TEST FAIL 669 DSBUS 3 SELF TEST FAIL 670 DSBUS 4 SELF TEST FAIL
671 PRIMARY AMP 1 FAIL 672 PRIMARY AMP 2 FAIL 673 PRIMARY AMP 3 FAIL 674 PRIMARY AMP 4 FAIL
675 BACKUP AMP 1 FAIL 676 BACKUP AMP 2 FAIL 677 BACKUP AMP 3 FAIL 678 BACKUP AMP 4 FAIL
679 BACKUP AMP NOT
INSTALLED
680 BACKUP AMP 1 NOT
INSTALLED
681 BACKUP AMP 2 NOT
INSTALLED
682 BACKUP AMP 3 NOT
INSTALLED
683 BACKUP AMP 4 NOT
INSTALLED
684 MODBUS
COMMUNICATIONS FAULT
685 VESDANET TROUBLE 686-724 RESERVED
725 ALARM SIGNAL
NOTE: This value may not exceed 90 seconds for ULC installations.
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
Table 9 System Trouble Names and Codes (Continued)
ACS Label Menu Screen (1)
ACS LABEL MENU
A01
ACS LABEL:
EAST WING SPEAKERS
TROUBLE REPORTING DELAY: 90
PAIRING: X MORE
PAIRED FSCS: NONE ACCEPT
BACK
ACS Label Menu Screen (2)
ACS LABEL MENU
A01
<-ZONE SELECTION UP
SG1
SG2 DOWN
SG3
SG4
SG5 MORE
SG6
SG7
SG8 ACCEPT
VIEW BACK
