24 NFS2-640 UL Listing Document — P/N 52741LD:H9 5/19/2022
Programming Level: Program Change
1 = PROGRAMMING
Program Change (High Level)
1 = BASIC PROGRAM
0 = CLR (Clear Program)
1 = AUTO (Autoprogram)
2 = POINT (Point Program)
1 = MODIFY POINT
2 = DELETE POINT
3 = PASSWD (Password)
* = PROGRAM (Program Password Level)
# = STATUS (Status Password Level)
4 = MESSAGE (All Systems Normal Message)
5 = ZONES (Zone Programming)
6 = SPL FUNCT (Special Function)
F0 = PRESIG (Presignal Delay/PAS)
R0-R9 = REL (Releasing Zones)
F5-F6 = TIME (Time Function)
F7 = HOL (Holiday)
F8 = CODE (Coding Function)
F9 = PRE-ALARM
7 = SYSTEM (System Programming)
SIL INH (Silence Inhibit)
AUTO (Auto Silence Timer)
VERIFY (Alarm Verification)
USA TIME
TERM (Terminal Supervision)
AC DLY (AC Delay)
LocT (Terminal Location)
BLINK (Device Blink)
ST (SLC Wiring Style)
ACS (Annunciator Programming)
8 = CHECK PRG (Check Programming)
2 = NETWORK (Network Programming)
THRESHOLD CH. A
THRESHOLD CH. B
NODE (Network Node Number)
STYLE (Network Wiring Style)
3 = UTILITY (Utility Programming)
REGION
TBL. REMIND (Trouble Reminder)
ALA. SCROLL (Alarm Scroll)
LOCAL CONTROL
IP-ACCESS
DCC MODE (Display and Control Center)
4 = FLASHSCAN POLL
L1DET (Loop 1 Detectors)
L1MOD (Loop 1 Modules)
L2DET (Loop 2 Detectors)
L2MOD (Loop 2 Modules)
Status Change (Low Level)
1 = DISABL (Disable/Enable Point)
2 = SENSITIV (Detector Sensitivity)
3 = CLR VER (Clear Alarm Verification Counters)
4 = CLR HIST (Clear History Buffer)
5 = TIME (Set System Time and Date)
6 = WALK TEST
NOTE: During a local or network Walk Test, activating a Mass Notification device will activate associated special function zones according to
CBE programming and simulate a Mass Notification event. Any network nodes, zones, or devices not participating in Walk Test will not participate
in the simulated Mass Notification event.
Choose one of the Program Change selections: 1, 2, 3 or 4
1 Basic Program options
3 Utility Program options
4 FlashScan Poll options
2 Network Program options
1=BASIC PROGRAM 2=NETWORK
3-UTILITY 4=FLASHSCAN POLL
0=CLR 1=AUTO 2=POINT 3=PASSWD 4=MESSAGE
5=ZONES 6=SPL FUNCT 7=SYSTEM 8=CHECK PRG
THRESHOLD CH.A:H, THRESHOLD CH.B:H
NODE: .000, CLASSA:Y, <ENTER>
REGION=0 TBL.REMIND=2 ALA.SCROLL=N
LOCAL CONTROL=0
FLASHSCAN L1DET L1MOD L2DET L2MOD
NYNY
Special Zone Lets you
F0=PRESIG Select a Presignal Delay Timer and select PAS (Positive Alarm Sequence)
F5-F6=TIME Specify Time Control functions such as the start time, stop time, or days of
the week
F7=HOL Specify up to nine holiday dates. An F7-programmed device activates on
the specified holiday dates
F8=CODE Specify one of the following coding function selections: March Time,
Temporal, California, Two-Stage, Two-Stage Canada (3 minute or 5
minute), Two-Stage Canada Manual, System Sensor Strobes, Gentex
Strobes, or Wheelock Strobes. F8 only takes effect if you program one or
more NACs to F8
F9=PRE-ALARM Select a Pre-Alarm level: Alert or Action
FA
†
(ZF10*) Turn on when detector in verification mode. This is a fixed point and is not
programmable
FB
†
(ZF16*) Turn on if custom drill set to Y and the panel in Drill mode (Alarm Signal On
in Canadian applications).
FC
†
(ZF18*) Turn on when a CO alarm occurs.
FD
†
(ZF20*) Turn on when a Mass Notification Alarm occurs (Does not apply for First
Command applications)
FE
†
(ZF21*) Turn on when a Mass Notification Supervisory occurs
FF
†
(ZF22*) Turn on when a Mass Notification Trouble occurs
ZF36*
If the local control active LED is on, this special zone will activate
ZF37*
Automatic Alarm Signal Activation Timer will turn on when the first alert
stage has been entered.
ZF38*
Turns on when the panel enters the second (evacuation) stage.
ZF39*
+
Automatic Alarm Signal Timer canceled. Can only be canceled if there is an
ACS button mapped to this zone.
ZF40*
Auto Silence Activation. ZF40 will activate when the auto silence timer has
expired and silenceable outputs on the fire panel have been silenced as a
result. ZF40 will remain active until a system reset, resound, or drill (alarm
signal On for Canadian applications) is performed.
R0-R9=REL Program up to ten Releasing Zones, each with a selection for a Delay
Timer, an Abort Switch, a Cross Zone selection, or a Soak Timer
* VeriFire Tools settings.
†
Not field programmable. Used for CBE programming only
Table 3 Summary of Special Function Zones
