34 NFS2-640 UL Listing Document — P/N 52741LD:H9 5/19/2022
• The control panel provides a 1-hour timer for Walk Test mode. When the hour expires with no activity, the control panel automatically returns to
normal operation.
• Walk Test may be exited at any time by pressing the ESC key.
Basic Walk Test
When the tester activates an input during Basic Walk Test, all silenceable outputs mapped by CBE to that input will activate. The activations are track-
ing; once the activation stimulus is removed, the input will deactivate. Basic Walk Test may be audible or silent, depending on the Walk Test setting of
participating outputs. Program the Walk Test field for control modules and NACs as follows:
Enter Basic Walk Test in the following manner. From the “Status Change Selection” screen, press the 6 key. The control panel dis-
plays the “Walk Test” screen as shown below:
Operate the control panel in Walk Test as follows
Basic Walk Test directs the control panel to do the following:
• Activate silenceable outputs associated by programming with each new alarm. (The panel does not activate non-silenceable outputs.)
• Save and store each test in the History buffer
• Send a TEST Axx status banner for each alarm, and a TEST TXX banner for each trouble, to the printer (xx equals the number of tests for a
detector or input device with this address)
• Turn on the System Trouble LED
• Turn on the System Trouble relay
• Disable activation of the System Alarm relay
Advanced Walk Test
During Advanced Walk Test, when the tester activates an input, all CBE mapped to that input will activate with the exception of releasing functions.
Each input activation is latching; that is, it will not deactivate until the system is reset. Advanced Walk Test will sound all activated outputs, overriding
a setting of “*” (silent) in the Walk Test field.
Enter Advanced Walk Test as follows:
Enter LTEST at the password screen. Asterisks will display where LTEST has been typed. Pressing ENTER displays the following
screen.
WARNING: FIRE PROTECTION DEACTIVATED
WALK TEST MODE DEACTIVATES FIRE PROTECTION. ALWAYS OBSERVE THE FOLLOWING:
1. PRIOR TO WALK TEST, SECURE ALL PROTECTED BUILDINGS, AND NOTIFY THE BUILDING OWNER/OPERATOR,
FIRE DEPARTMENT, AND OTHER PERTINENT PERSONNEL THAT TESTING IS IN PROGRESS.
2. IMMEDIATELY AFTER WALK TEST IS COMPLETED, NOTIFY THE SAME PEOPLE THAT TESTING IS COMPLETE AND
IS RESTORED TO NORMAL OPERATION.
WARNING: RELEASING DEVICES MUST BE PHYSICALLY DISCONNECTED
DO NOT RELY ON DISABLE/ENABLE SOFTWARE SETTINGS TO LOCKOUT RELEASING DEVICES.
NOTE: Walk Test will not start if any devices are active (i.e., fire alarms, security, supervisories or pre-alarms.) To perform a walk test while a
device is active, disable the device and press the System Reset button.
For Program Silenceable Outputs with Silenceable Outputs will
an audible Basic Walk Test W sound for approximately 4 seconds during Walk Test
a silent Basic Walk Test * not sound during Walk Test
a trouble Basic Walk Test W sound for approximately 8 seconds when put into trouble
Table 11 Walk Test Operation
To Press
Put the control panel into Walk Test mode
Stop a Walk Test and return to the “Status Change Selection” screen
NOTE: Some detectors, laser detectors for example, can be difficult to place in alarm using a magnet. Advanced Walk Test facilitates magnet
testing of these detectors.
WALK TEST PRESS ENTER TO START
ESCAPE TO ABORT
TROUBL IN SYSTEM ADV WALK TEST
PROCESSING DISABLED 10:07a 041508 MON
