30 NFS2-640 Operations P/N 52743:L4 06/10/19
Operation of the Control Panel Active Supervisory Signal Mode of Operation
Monitor Modules
Type Code
Latching
(Y/N)
Purpose What it does
WATERFLOW S Y Indicates supervisory condition for activated waterflow switch Lights
SUPERVISORY LED and activates CBE
RF SUPERVSRY N Monitors a radio frequency device Lights
SUPERVISORY LED and activates CBE
LATCH SUPERV Y Indicates latching supervisory condition Lights
SUPERVISORY LED and activates CBE
TRACK SUPERV N Indicates tracking supervisory condition Lights
SUPERVISORY LED and activates CBE
SPRINKLR SYS Y Indicates activation of sprinkler system Lights
SUPERVISORY LED and activates CBE
TAMPER Y Indicates activation of tamper switch Lights
SUPERVISORY LED and activates CBE
Detectors
SUP.T(DUCTI) N Ion detector that indicates supervisory (non-alarm) condition Lights SUPERVISORY LED and activates CBE
SUP.L(DUCTI) Y Ion detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUPT(DUCTL) N Laser detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUPL(DUCTL) Y Laser detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUP.T(DUCTP) N Photo detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUP.L(DUCTP) Y Photo detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUPT(PHOTO) N Photo detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUP.L(PHOTO) Y Photo detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUP.T(ION) N Ion detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUP.L(ION) Y Ion detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUP.L(LASER) Y Laser detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
SUP.T(LASER)
N
Laser detector that indicates supervisory (non-alarm) condition Lights
SUPERVISORY LED and activates CBE
P/CO (C SUP)* Y Indicates activation of the Photo, Heat or CO element of a
detector. LED representation of a CO alarm may be performed
using an ACS annunciator.
Activation of the Heat or Photo elements will
light an indicator at the control panel.
Activation of the CO element will light the
SUPERVISORY LED. Activates CBE.
P/CO (P SUP)* Y
Indicates activation of the Photo, Heat or CO element of a
detector. FlashScan only. No Pre-Alarm. Requires approval of
AHJ. LED representation of a CO alarm may be performed
using an ACS annunciator. Photo element can be programmed
as latching or tracking for all Photo/CO devices programmed
as this type ID via VeriFire Tools.
Activation of the Heat element will light an
indicator at the control panel.
Activation of the CO element will not light
and indicator at the control panel.
Activation of the Photo element will light the
SUPERVISORY LED. Activates CBE.
NOTE: For Photo/CO detectors:
Detectors programmed as P/CO (P SUP), the heat and CO elements will latch and require a system reset to clear. The Photo element will
latch or track, depending on the Photo/CO (Photo SUP) setting. Detectors programmed as P/CO (C SUP), the heat and Photo elements will
latch and require a system reset to clear. The CO element will latch or track depending on the Photo/CO (CO SUP) setting. For Photo/CO
and CO Detectors programmed as Photo/CO (P SUP) or CO (CO SUP) will either latch and track, depending on the setting.
ACCL (P SUP) Y (see
note
below)
Combination Photoelectric/Heat detector. Photo element
activation generates a supervisory condition FlashScan only.
No Pre-Alarm.
Lights
SUPERVISORY LED and activates CBE
ACCL+ (P SUP) Y (see
note
below)
Combination Photoelectric/Heat detector with low temperature
warning. Photo element activation generates a supervisory
condition. FlashScan only. No Pre-Alarm.
Lights
SUPERVISORY LED and activates CBE
NOTE: For ACCL/ACCL+ detectors:
Detectors programmed as ACCL (P SUP) or ACCL+ (P SUP), the heat element will latch and require a system reset to clear. The Photo
element will latch or track, depending on the ACCL (P SUP) latching setting.
*FlashScan only
Table 3.4 Supervisory Type Codes
