NFS2-640 Operations P/N 52743:L4 06/10/19 35
Active Trouble Monitor Mode of Operation Operation of the Control Panel
3.11.3 Interpreting CO Alarm/Supervisory Type Codes
The Type Code that displays in the CO Alarm message indicates the function of the point that initi-
ates the CO alarm. For example, a monitor module with a
CO MONITOR Type Code means that the
monitor module monitors a conventional CO detector. The table below lists the Type Codes that
can appear in an alarm message:
3.12 Active Trouble Monitor Mode of Operation
3.12.1 How the Control Panel Indicates an Active Trouble Monitor
Trouble Monitor Points are monitor modules programmed with the following Type Codes:
These types of monitor modules operate like monitored system functions that can produce trou-
bles—but with the following differences:
Type Code
Latching
(Y/N)
Purpose What it does
Monitor Modules
CO Monitor* Y Indicates activation of a CO conventional detector Activates CBE, does not light an indicator
at the control panel.
Detectors
PHOTO/CO*
,4
Y Indicates activation of the Photo, Heat, or CO element of a
detector.
Lights FIRE ALARM LED for photo and heat,
no LED will light for a CO alarm. Photo and
heat will activate CBE, CO alarm activates
special function zone FC and sixth CBE
zone only (sixth CBE zone programmable
via VeriFire Tools)
P/CO (P SUP)*,
2,4,5
Y Indicates activation of the Photo, Heat or CO element of a
detector.
Lights FIRE ALARM LED for heat, no LED will
light for a CO alarm, supervisory LED will
light for photo alarm, heat and photo will
activate CBE, CO alarm activates special
function zone FC and sixth CBE zone only
(sixth CBE zone programmable via VeriFire
Tools)
P/CO (C SUP)*
,4
Y Indicates activation of the Photo, Heat or CO element of a
detector.
Lights FIRE ALARM LED for heat and photo
alarms, will light supervisory LED for CO
alarm, photo and heat alarms will activate
CBE, CO alarm will activate sixth CBE
zone only (sixth CBE zone programmable
via VeriFire Tools)
*FlashScan mode only
1
2
Requires approval of AHJ.
3
Not suitable for Canadian applications.
4
LED representation of a CO alarm may be performed using an ACS annunciator.
5
Photo element can be programmed as latching or tracking for all Photo/CO devices programmed as this type ID via VeriFire Tools.
Table 3.6 CO Alarm Type Codes
Type Code
Latching
(Y/N)
Device Function Point Function
AUDIO SYSTEM
N
Used for monitoring audio equipment audio
amplifiers or associated equipment
Indicates trouble
EQUIP MONITR
N
Used for recording access to monitored equipment Activates CBE
POWER MONITR
N
Used to monitor remote power supplies or other
external equipment
Indicates trouble
TROUBLE MON
N
Used to monitor remote power supplies or other
external equipment
Indicates trouble
Table 3.7 Trouble Monitor Type Codes
