NFS2-640 Operations P/N 52743:L4 06/10/19 33
CO Alarm Mode of Operation Operation of the Control Panel
3.10.2 How the Control Panel Indicates an Active Fire Control
Activation of a FIRE CONTROL point causes the control panel to do the following:
• Initiate the monitor module Control-by-Event
• Send a message to the LCD display, History buffer and installed printers, FDU-80
annunciators, and CRT-2s
• Display an
ACTIVE status banner and FIRE CONTROL Type Code on the LCD display, along with
information specific to the device
Figure 3.15 Sample Fire Control Point Display
3.10.3 How the Control Panel Indicates an Active Non-Fire Point
Non-Fire point operation does not affect control panel operation, nor does it display a message at
the panel LCD. Activation of a Non-Fire point activates CBE—but does not cause any indication
on the control panel. For example, you can program a Non-Fire point to turn lights in a zone to a
lower setting when activated. In this case, when the point activates the control panel activates the
point’s CBE to turn the lights down without any audio or visual indication on the control panel.
3.11 CO Alarm Mode of Operation
3.11.1 How the Control Panel Indicates a CO Alarm
When an initiating device (detector or monitor module) activates due to a CO alarm event, the con-
trol panel does the following:
• Produces a pulsed audible tone
• Displays a CO alarm event that indicates the type of device that activated the fire alarm
ACK SWITCH N Performs Acknowledge function Silences panel sounder, gives an
Acknowledge message on the panel LCD
ALLCALL PAGE N Activates all speaker circuits for paging Activates speakers
DRILL SWITCH N Performs Drill function (Not for use in Canadian
applications.)
Activates silenceable outputs
FIRE CONTROL N Used for air handler shutdown, intended to override
normal operating automatic functions
Activates CBE, does NOT light an
indicator at the control panel
NON-FIRE N Used for energy management or other non-fire
situations. Does not affect operation of the control panel
Activates CBE, does NOT light an
indicator at the control panel
PAS INHIBIT N Inhibits Positive Alarm Sequence Inhibits Positive Alarm Sequence
RESET SWITCH N Performs Reset function Resets control panel
SIL SWITCH N Performs Signal Silence function Turns off all activated silenceable outputs
TELE PAGE N Performs function of Page Button on FFT-7 Allows remote paging to a fire area
ABORT SWITCH N Indicates Active at the panel Aborts activation of a releasing zone
Table 3.5 Non-Alarm Type Codes (2 of 2)
Status banner
Type Code
Zone affected by the Fire Control
ACTIVE FIRE CONTROL INTENSIVE CARE UNIT
EASTERN WING Z055 08:59a 071415 1M044
