54 NFS2-640 Operations P/N 52743:L4 06/10/19
Read Status Operation Viewing and Printing a Read Status
How to Print Points
Option 1 (PRNT POINT=1) lets you print a list of all points programmed into
the system. From the “Read Status” screen, press 1, then press the
ENTER
key to print a list of installed points. A sample Print Point screen is shown
below:
Figure 4.21 Sample Print Point Display
A sample printout of three points using the Print Point option:
How to Print Event History
Option 3 (HIST=3) lets you print a list of all events in the History buffer (up
to 800). From the “Read Status” screen, press 3, then press the
ENTER key to
print a list of events. A sample History Print screen is shown below:
Figure 4.22 Sample History Print Screen
A sample printout of three events in history using the History Print option:
How to Print Alarm History
Option 5 (ALARM HIST=5) lets you print a list of alarm events in the History
buffer (up to 200). From the “Read Status” screen, press 5, then press the
ENTER key to print a list of alarm events. A sample Print Alarm History
screen is shown below:
Figure 4.23 Sample Print Alarm History Display
A sample printout of two alarm events in the History buffer using the Print Alarm History option.
NORMAL SMOKE(PHOTO) DETECTOR ADDR 1D043 Z003 000%A8 8 ** 1D043
NORMAL SMOKE(PHOTO) DETECTOR ADDR 1D044 Z003 000%A8 8 ** 1D044
NORMAL SMOKE(PHOTO) DETECTOR ADDR 1D045 Z003 000%A8 8 ** 1D045
******************** EVENT HISTORY START****************************************
SYSTEM RESET 02:28P 042408 Thu
ALARM: SMOKE (ION) DETECTOR ADDR 1D075 Z002 02:28P 042408 1D075
ALARM: SMOKE (ION) DETECTOR ADDR 1D076 Z002 02:28P 042408 1D076
ACKNOWLEDGE 02:28P 042408 Thu
********************ALARM HISTORY START ****************************************
ALARM: SMOKE (ION) DETECTOR ADDR 1D075 Z002 02:28P 012208 1D075
ALARM: SMOKE (ION) DETECTOR ADDR 1D076 Z002 02:28P 012208 1D076
******************* PRINT END ****************************************
