The SCS⁄SCE Building-Specific Operation and Programming Examples
The point assignments for the SCS⁄SCE at address 6 and the SCS⁄SCE at address 7 are the same. Each are as follows:
All of the protocol points with software type IDs must be entered in FACP memory. Refer to Table 3.13 for protocol point software type IDs
and Section 2.4.4, Full Point Programming, for instructions on programming EIA-485 protocol points.
After programming of all protocol points is complete, the programming associated with the control and monitor modules must take place,
including software type IDs, Control-By-Event, and protocol point mapping. This will be accomplished by using full point programming.
Before beginning full point programming, determine all parameters associated with each control module and monitor module. Worksheet 3
will assist in the organization of information required for programming control and monitor modules.
Point Assignments: classification type ID Point Assignments: classification type ID
1(CON
ON⁄OP
) needed ACON 17 (CON
ON⁄OP
) needed ACON
2(CON
OFF⁄CL
) needed ACON 18 (CON
OFF⁄CL
) needed ACON
3 (VER
ON⁄OP
) needed AMON 19 (VER
ON⁄OP
) needed AMON
4(VER
OFF⁄CL
) needed AMON 20 (VER
OFF⁄CL
) needed AMON
5(CON
ON⁄OP
) needed ACON 21 (CON
ON⁄OP
) needed ACON
6(CON
OFF⁄CL
) needed ACON 22 (CON
OFF⁄CL
) needed ACON
7 (VER
ON⁄OP
) needed AMON 23 (VER
ON⁄OP
) needed AMON
8(VER
OFF⁄CL
) needed AMON 24 (VER
OFF⁄CL
) needed AMON
9(CON
ON⁄OP
) needed ACON 25 (CON
ON⁄OP
) needed ACON
10 (CON
OFF⁄CL
) needed ACON 26 (CON
OFF⁄CL
) needed ACON
11 (VER
ON⁄OP
) needed AMON 27 (VER
ON⁄OP
) needed AMON
12 (VER
OFF⁄CL
) needed AMON 28 (VER
OFF⁄CL
) needed AMON
13 (CON
ON⁄OP
) needed ACON 29 (CON
ON⁄OP
) needed ACON
14 (CON
OFF⁄CL
) needed ACON 30 (CON
OFF⁄CL
) needed ACON
15 (VER
ON⁄OP
) needed AMON 31 (VER
ON⁄OP
) needed AMON
16 (VER
OFF⁄CL
) needed AMON 32 (VER
OFF⁄CL
) needed AMON
Point Assignments: classification type ID Point Assignments: classification type ID
33 (CON
ON⁄OP
) needed ACON 49 (CON
ON⁄OP
) needed ACON
34 (CON
OFF⁄CL
) needed ACON 50 (CON
OFF⁄CL
) needed ACON
35 (VER
ON⁄OP
) needed AMON 51 (VER
ON⁄OP
) needed AMON
36 (VER
OFF⁄CL
) needed AMON 52 (VER
OFF⁄CL
) needed AMON
37 (CON
ON⁄OP
) needed ACON 53 (CON
ON⁄OP
) needed ACON
38 (CON
OFF⁄CL
) needed ACON 54 (CON
OFF⁄CL
) needed ACON
39 (VER
ON⁄OP
) needed AMON 55 (VER
ON⁄OP
) needed AMON
40 (VER
OFF⁄CL
) needed AMON 56 (VER
OFF⁄CL
) needed AMON
41 (CON
ON⁄OP
) needed ACON 57 (CON
ON⁄OP
) needed ACON
42 (CON
OFF⁄CL
) needed ACON 58 (CON
OFF⁄CL
) needed ACON
43 (VER
ON⁄OP
) needed AMON 59 (VER
ON⁄OP
) needed AMON
44 (VER
OFF⁄CL
) needed AMON 60 (VER
OFF⁄CL
) needed AMON
45 (CON
ON⁄OP
) needed ACON 61 (CON
ON⁄OP
) needed ACON
46 (CON
OFF⁄CL
) needed ACON 62 (CON
OFF⁄CL
) needed ACON
47 (VER
ON⁄OP
) needed AMON 63 (VER
ON⁄OP
) needed AMON
48 (VER
OFF⁄CL
) needed AMON 64 (VER
OFF⁄CL
) needed AMON
