34 SCS Series Manual — P/N 15712:L 7/18/16
The SCS⁄SCE Smoke Control Station (SCS-8)
Local Acknowledge / Lamp
Test momentary switch
All AUTO LED (Green)
Manual LED (Amber)
On LED (Green)
3 - position
toggle switch
(ON/AUTO/OFF)
Off LED (Yellow)
Trouble LED
(Amber)
Switch
Group
8 dipswitches
SCS8.wmf
SCS-8 (top view)
Two rotary decimal
address switches
SCS-SWIT.wmf
Figure 3.1 SCS-8
