Building-Specific Operation and Programming Examples The SCS⁄SCE
Point assignments for SCS at address 5:
Since an SCE is not used at address 5, switches 9-16 are not used. Subsequently protocol points 33-64 are unused and are assigned the soft-
ware type ID ACON.
Point assignments for the SCS⁄SCE pair at address 6 and for the pair at address 7:
Point Assignments: classification type ID Point Assignments: classification type ID
1(CON
ON⁄OP
) needed ACON 17 (CON
ON⁄OP
) unused ACON
2(CON
OFF⁄CL
) unneeded - 18 (CON
OFF⁄CL
) unused ACON
3 (VER
ON⁄OP
) needed AMON 19 (VER
ON⁄OP
) unused ACON
4(VER
OFF⁄CL
) unneeded - 20 (VER
OFF⁄CL
) unused ACON
5(CON
ON⁄OP
) needed ACON 21 (CON
ON⁄OP
) unused ACON
6(CON
OFF⁄CL
) unneeded - 22 (CON
OFF⁄CL
) unused ACON
7 (VER
ON⁄OP
) needed AMON 23 (VER
ON⁄OP
) unused ACON
8(VER
OFF⁄CL
) unneeded - 24 (VER
OFF⁄CL
) unused ACON
9(CON
ON⁄OP
) needed ACON 25 (CON
ON⁄OP
) unused ACON
10 (CON
OFF⁄CL
) unneeded - 26 (CON
OFF⁄CL
) unused ACON
11 (VER
ON⁄OP
) needed AMON 27 (VER
ON⁄OP
) unused ACON
12 (VER
OFF⁄CL
) unneeded - 28 (VER
OFF⁄CL
) unused ACON
13 (CON
ON⁄OP
) needed ACON 29 (CON
ON⁄OP
) unused ACON
14 (CON
OFF⁄CL
) unneeded - 30 (CON
OFF⁄CL
) unused ACON
15 (VER
ON⁄OP
) needed AMON 31 (VER
ON⁄OP
) unused ACON
16 (VER
OFF⁄CL
) unneeded - 32 (VER
OFF⁄CL
) unused ACON
Point Assignments: classification type ID Point Assignments: classification type ID
1(CON
ON⁄OP
) needed ACON 17 (CON
ON⁄OP
) needed ACON
2(CON
OFF⁄CL
) unneeded - 18 (CON
OFF⁄CL
) unneeded -
3 (VER
ON⁄OP
) needed AMON 19 (VER
ON⁄OP
) needed AMON
4(VER
OFF⁄CL
) needed AMON 20 (VER
OFF⁄CL
) needed AMON
5(CON
ON⁄OP
) needed ACON 21 (CON
ON⁄OP
) needed ACON
6(CON
OFF⁄CL
) unneeded - 22 (CON
OFF⁄CL
) unneeded -
7 (VER
ON⁄OP
) needed AMON 23 (VER
ON⁄OP
) needed AMON
8(VER
OFF⁄CL
) needed AMON 24 (VER
OFF⁄CL
) needed AMON
9(CON
ON⁄OP
) needed ACON 25 (CON
ON⁄OP
) needed ACON
10 (CON
OFF⁄CL
) unneeded - 26 (CON
OFF⁄CL
) unneeded -
11 (VER
ON⁄OP
) needed AMON 27 (VER
ON⁄OP
) needed AMON
12 (VER
OFF⁄CL
) needed AMON 28 (VER
OFF⁄CL
) needed AMON
13 (CON
ON⁄OP
) needed ACON 29 (CON
ON⁄OP
) needed ACON
14 (CON
OFF⁄CL
) unneeded - 30 (CON
OFF⁄CL
) unneeded -
15 (VER
ON⁄OP
) needed AMON 31 (VER
ON⁄OP
) needed AMON
16 (VER
OFF⁄CL
) needed AMON 32 (VER
OFF⁄CL
) needed AMON
