Honeywell Orbit MS7120 User Manual

1
INTRODUCTION
Orbit
®
is an aggressive, omnidirectional laser bar code scanner ideal for use in
retail, convenience, liquor and specialty stores Designed to be lightweight and
rugged, Orbit’s small size makes it ideal for applications where counter space is
limited. The MS7120 unique contoured shape allows it to be picked-up and used
as a hand-held scanner when scanning large or bulky items.
Key Product Features
 Fully Automatic Scanning Operation
 Adjustable Scan Head
 User-Replaceable Single Cable Interface To Host (Powerlink Compatible)
 Seven Beeper Tones
 Configurable Depth of Field
 Firmware updates are easily loaded into Flash memory
 OPOS and JPOS System Compatible
 Support For Common Interfaces Including USB (See Table Below)
 Easy Bar Code Configuration
ORBIT
MODEL NUMBER
INTERFACE
MS7120-38
RS232 Low Speed USB,
Keyboard Emulation Mode or Serial Emulation Mode*
MS7120-41 RS232/Light Pen Emulation
MS7120-47
Keyboard Wedge,
Stand-Alone Keyboard and RS232 Transmit/Receive
MS7120-106 RS485

and Full Speed USB
* Configurable for Keyboard Emulation Mode or Serial Emulation Mode.
Default setting is Keyboard Emulation Mode.

Applicable for IBM
®
Host applications.

Honeywell Orbit MS7120 Specifications

General

Wavelength	650 nm
Scanner type	1D
Light levels (direct sunlight)	0 - 4842 lx
Bluetooth	No
Standard interfaces	USB
Input voltage	5 V
Product color	Black
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	105 mm
Width	102 mm
Height	150 mm
Weight	400 g
