PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 11
Setup
Setting Jumpers
Table 1: Jumper Settings
Setting DIP Switches
Table 2: DIP Switch Settings
Jumper Setting Default Selected
J1
OFF * Port 1 RS-485 EOL terminator is not active
ON Port 1 RS-485 EOL terminator is active
J2
OFF Reader 0 Power Terminal provides 5 VDC
ON * Reader 0 Power Terminal provides 12 VDC
J3
OFF Reader 1 Power Terminal provides 5 VDC
ON * Reader 1 Power Terminal provides 12 VDC
S8 S7 S6 S5 S4 S3 S2 S1 Selection
OFF OFF OFF OFF OFF ADDRESS 0
OFF OFF OFF OFF ON ADDRESS 1*
OFF OFF OFF ON OFF ADDRESS 2
OFF OFF OFF ON ON ADDRESS 3
OFF OFF ON OFF OFF ADDRESS 4
OFF OFF ON OFF ON ADDRESS 5
OFF OFF ON ON OFF ADDRESS 6
OFF OFF ON ON ON ADDRESS 7
OFF ON OFF OFF OFF ADDRESS 8
OFF ON OFF OFF ON ADDRESS 9
OFF ON OFF ON OFF ADDRESS 10
OFF ON OFF ON ON ADDRESS 11
OFF ON ON OFF OFF ADDRESS 12
OFF ON ON OFF ON ADDRESS 13
OFF ON ON ON OFF ADDRESS 14
OFF ON ON ON ON ADDRESS 15
ON OFF OFF OFF OFF ADDRESS 16
ON OFF OFF OFF ON ADDRESS 17
ON OFF OFF ON OFF ADDRESS 18
ON OFF OFF ON ON ADDRESS 19
ON OFF ON OFF OFF ADDRESS 20
ON OFF ON OFF ON ADDRESS 21
ON OFF ON ON OFF ADDRESS 22
ON OFF ON ON ON ADDRESS 23
ON ON OFF OFF OFF ADDRESS 24
