PX4i and PX6i High Performance Printer User Guide 37
To load media for printing from an external supply
1. (Optional) Fit the fanfold guides in either the upper or lower slot. The outer
guide is adjustable for various media widths. The minimum width is 40 mm
(1.58 in).
• Fit the fanfold guide into the upper slot in the rear plate when the supply is at the
same level as the printer or in peel-off mode.
• Fit the fanfold guide into the lower slot in the rear plate when the supply is
placed lower than the printer.
2. Feed the media through the slot in the rear plate.
Feeding Media Through the Upper Slot

Honeywell PX4i Specifications

General

Print Technology	Thermal Transfer
Resolution	300 dpi
Max Print Width	4.09 inches
Max Print Speed	10 ips (inches per second)
Connectivity	USB, Serial, Ethernet
Memory	16 MB Flash, 32 MB SDRAM
Supported Media Types	Labels, tags
Supported Media Width	19 mm (0.75 in) to 110 mm (4.33 in)
