The figure below shows the components of the Recess Mounting Box SC116. For more
information, please refer to “The Recess Mounting Box SC116 User Guide”.
Figure 6-10 Recess Mounting Box SC116 Components
Wall Plate Mounting Box
The Floor Mounting Box SC117
The Floor Mounting Box SC117 is designed to provide an easy way to recess the detector in the
floor and protect the detector from external destruction.
The figure below shows the components of the Floor Mounting Box SC117. For more information,
please refer to “The Floor Mounting Box SC117 User Guide”.
Figure 6-11 Floor Mounting Box SC117 Components
Floor Plate
Mounting Box
