EDA52 User Guide 89
Note: To learn about changing the symbology settings, see Change the Scanner Settings on
page 36.
S0703-SR (Standard Range) Imager
The depth of field measurements used the following parameters:
• Distances are measured from the front of the Imager.
• +23°C (+73 °F), 0 lux for guaranteed, 200 lux for typical.
• Photographic quality codes
Note: Time to Read and Depth of Field are impacted if the barcode symbol is at the edge of
the image.
Guaranteed Specs
MSI Disabled
Telepen Disabled
Trioptic Disabled
UPC/EAN Enabled
UPC-A Enabled
UPC-E Enabled
1D Symbologies 2D Symbologies Postal Codes
Default Default Default
Focus Standard Range
Symbology Near Distance Far Distance
5 mils Code 39 mm 79 270
in. 3.11 10.63
10 mils Code 39 mm 40 450
in. 1.57 17.72
20 mils Code 39 mm 44 674
in. 1.73 26.53
13 mils 100% UPC-A mm 44 515
in. 1.73 20.27
15 mils Code 128 mm 42 572
in. 1.65 22.52
10 mils Data Matrix mm 83.1 236
in. 3.27 9.29
5 mils PDF 417 mm 119 177.04
in. 4.68 6.97
