DESIGN SPECIFICATIONS
OPERATIONAL
Light Source: VLD 650 ± 10 nm
CDRH/IEC:
Designed to be used in CDRH Class II and
IEC Class 2 laser products
UL:
UL recognized component for Canada and
US
Standard: 25 mm to 200 mm (1" to 8")
Depth of Field, UPC 100%
(0.33 mm (13 mil) bar codes):
High Density: 10 mm to 175 mm (0.4" to 6.9")
Scan Speed: 52 scan lines per second minimum
Scan Pattern: Single scan line
Standard: 0.173 mm (6.8 mil)
Resolution:
High Density: 0.132 mm (5.2 mil)
Roll, Pitch, Skew: 30°, 56°, 58° at 100 mm distance
Sweep Angle: 60°
Scan Width:
40 mm (1.57") @ Face; 280 mm (11.00") @
200 mm (8.00")
Print Contrast: 35% minimum reflectance difference
Decode Capability:
All standard 1D symbologies including GS1
DataBar
IS4125
System Interfaces:
RS232C, Light Pen Emulation,
Keyboard Wedge, Low Speed USB,
RS232 TTL
MAINTENANCE
Window: Clean Periodically
Specifications are subject to change without notice.
