7
DESIGN SPECIFICATIONS
MECHANICAL
Dimensions:
45.7 mm L x 40.6 mm W x 18.5 mm D
(1.8" L x 1.6" W x 0.73" D)
Weight: 53 g. (1.87 oz.)
IS4125
Termination:
Low profile ZIF 12-pin connector that accepts
a 1 mm x 12 position FFC/FPC cable
Dimensions:
45.7 mm L x 40.6 mm W x 14 mm D
(1.8" L x 1.6" W x 0.55" D)
Weight: 45 g. (1.774 oz.)
IS4110
Termination:
Low profile ZIF 10-pin connector that accepts
a 1 mm x 12 position FFC/FPC cable
ELECTRICAL
Power: 0.6 watts
Input Voltage: 5VDC ± 0.25V
Operating Current: 120 mA typical @5VDC
Sleep Current:
22 mA @ 5VDC – typical for RS232 C, TTL
RS232 and Keyboard Wedge
Suspend Current: 1 mA @ 5VDC – typical for USB
IS4125
Idle Current: 58 mA typical @ 5VDC
Power: 0.375 watts
Input Voltage: 5VDC ± 0.25V
Operating Current: 75 mA typical @ 5VDC
IS4110
Standby Current: 1.7 mA typical @ 5VDC
Specifications are subject to change without notice.
