113
MAN0530 Issue 09 October 03 Searchline Excel
2104M0506
The calibration status fields and values are given below:
Calibration Status Fields Display Text False State True State
Temperature Cal. Temp Sensor Uncalibrated Calibrated
Zero Calibration Zero Ratio Uncalibrated Calibrated
Span Calibration Span Sensitivity Uncalibrated Calibrated
4-20mA Calibration Analogue Output Uncalibrated Calibrated
Det. Temp. Comp. T Compensation Uncalibrated Calibrated
Det. Sens. Comp. Det Sensitivity Uncalibrated Calibrated
Installation Installation Required Complete
Valid Date Time Date and Time Estimated Set
Loop Test Analogue Check Failed Passed
A.5.4 Diagnose Menu
This sub menu has the following options:
Active Faults Display the active faults in the system.
Active Warns Display the active warnings in the system.
Self Test Perform a diagnostic system self test.
Soft Reset Reset the system.
Active Faults
This menu option displays operational faults when the system is in service.
If there are one or more faults present, then the faults are displayed one at a time.
Use the and keys to navigate the list.
If no active faults are present the display shows the following for three seconds:
None Present
The Diagnose sub menu is then displayed.
If there are one or more faults present, the display shows:
F-hh:mm DD/MM/YY
eeeeeeeeeeeeeeee
where: F Indicates that the message displayed is a fault.
hh:mm Time the fault occurred.
DD/MM/YY Date the fault occurred.
eeeeeee...Fault description. See the following table for a list of error
messages.
See also Chapter 6, Problem Solving.
APPENDIX A - HANDHELD INTERROGATOR
