2.1 INTRODUCTION
Each type of Searchline Excel gas detector consists of two units, a Transmitter and a Receiver.
ThisseparateTransmitter/Receivercongurationprovidesthemostreliablebasisforopenpath
gas detection.
2. OVERVIEW
DVC100(M) MK2 or DX100(M)
(or other junction box)
Mounting plate
Mounting bracket
Pivot block
Receiver
Flexible conduit
Monitored
path
5 - 200 m
Honeywell Analytics
Junction Box
00780-A-0100 (or
other junction box)
Transmitter
