Key Locations and Descriptions
SYSTEM
Cool Off Heat
Auto On
FAN
Hold
Select
TUE
P
M
M14673
HOLD KEY
• SET TEMPORARY TEMPERATURE HOLD.
HOLD KEY
• SET TEMPORARY TEMPERATURE HOLD.
INCREASE ▲ KEY
• PROGRAM TIME AND TEMPERATURE.
• SET TEMPORARY TEMPERATURE HOLD
.
INCREASE ▲ KEY
SELECT KEY
• CURRENT SETPOINT.
• CHANGE DAY AND TIME.
• PROGRAM SELECTIONS.
SELECT KEY
• CURRENT SETPOINT.
• CHANGE DAY AND TIME.
• PROGRAM SELECTIONS.
SYSTEM SWITCH
SYSTEM SWITCH
FAN SWITCH
FAN SWITCH
BATTERY
DOOR
DECREASE ▼ KEY
• PROGRAM TIME AND TEMPERATURE.
• SET TEMPORARY TEMPERATURE HOLD.
SYSTEM
Cool Off Heat
Auto On
FAN
Hold
Select
T
U
E
P
M
• PROGRAM TIME AND TEMPERATURE.
• SET TEMPORARY TEMPERATURE
HOLD.
T8000, T8001
T8011, T8024
MODELS
T8002 MODEL
