TB3 SERIES COMMUNICATING THERMOSTATS INSTALLATION INSTRUCTIONS
31-00576-01 16
TB3240 Series BACnet Registers
Analog Inputs
Analog Values for TB3140x
NO OBJECT VALUE
OBJECT
NAME
FUNCTION DEFAULT
READ (R)/
WRITE (W)
COV
PROPERTY
1
Analog
Input #1
-9.9 °C to 99.9 °C
(14 °F to 212 °F)
Room
Temperature
This parameter shows the
room temperature value.
- R COV
2
Analog
Input #2
-9.9 °C to 99.9 °C
(14 °F to 212 °F)
Universal
Input
Temperature
If “Universal Input” is “1”, ’2’’
or “3”, this parameter shows
the sensor temperature.
- R COV
NO OBJECT VALUE
OBJECT
NAME
FUNCTION DEFAULT
READ (R)/
WRITE (W)
COV
PROPERTY
1
Analog
Value #1
0 to 3 Mode
0 = Fan Only
1 = Heat
2 = Cool
3 = Auto
3 R/W COV
2
Analog
Value #2
1 to 4 Fan Speed
1 = Stage 1
2 = Stage 2
3 = Stage 3
4 = Auto
1 R/W COV
3
Analog
Value #3
Set Point Low
Limit to Set
Point High
Limit
Set Point
This parameter is the
desired room temperature
value.
21 °C
(70 °F)
R/W COV
4
Analog
Value #4
5°C to 40°C
(41°F to 104°F)
Set Point
High Limit
This parameter adjusts the
high limit for desired room
temperature.
30 ° C
(86 °F)
R/W -
5
Analog
Value #5
5°C to 40°C
(41°F to 104°F)
Set Point
Low Limit
This parameter adjusts the
low limit for desired room
temperature.
5 °C
(41 °F)
R/W -
6
Analog
Value #6
0 to 63 Key Lock
0 = Unlocked
1 = Lock On/Off
2 = Lock Mode
4 = Lock Setpoint
8 = Lock Fan Speed
16 = Lock Time Settings
32 = Lock Time Schedule
Settings 63 = Locked All
NOTE:
To lock two or more
buttons at the same
time, add the button
values. Enter 12 to
lock the setpoint (4)
and fan speed (8).
0 R/W -
