TB3 SERIES COMMUNICATING THERMOSTATS INSTALLATION INSTRUCTIONS
31-00576-01 18
Analog Values for TB3240x
19
Analog
Value #19
0 to 3 Fan Status
0 = Off
1 = Low
2 = Med
3 = High
0 R COV
20
Analog
Value #20
0 to 3 Alarm
This parameter indicates
the alarm state.
0 = No alarm
1 = Onboard Sensor Alarm
2 = External Sensor Alarm
3 = Changeover Sensor
Alarm
0 R COV
21
Analog
Value #21
2017 to 2099
Current
Year
This parameter adjusts the
current year.
2022 R/W -
22
Analog
Value #22
1 to 12
Current
Month
This parameter adjusts the
current month.
- R/W -
23
Analog
Value #23
1 to 31 Current Day
This parameter adjusts the
current day.
- R/W -
24
Analog
Value #24
00 to 23
Current
Hour
This parameter adjusts the
current hour.
- R/W -
25
Analog
Value #25
00 to 59
Current
Minute
This parameter adjusts the
current minute.
- R/W -
26
Analog
Value #26
1 to 4 Baud rate
1 = 9600bps
2 = 19200bps
3 = 38400bps
4 = 76800bps
4 R/W -
27
Analog
Value #27
1 to 9998
Parameter
Menu
Password.
This parameter adjusts the
password.
0 R/W
28
Analog
Value #28
0 to 2
File Transfer
Process
Information
0 = Firmware Confirmed
1 = Upload in Progress
2 = Upload Failed
0 R
NO OBJECT VALUE
OBJECT
NAME
FUNCTION DEFAULT
READ (R)/
WRITE (W)
COV
PROPERTY
NO OBJECT VALUE
OBJECT
NAME
FUNCTION DEFAULT
READ (R)/
WRITE (W)
COV
PROPERTY
1
Analog
Value #1
0 to 3 Mode
0 = Fan Only
1 = Heat
2 = Cool
3 = Auto
3 R/W COV
2
Analog
Value #2
1 to 4 Fan Speed
1 = Stage 1
2 = Stage 2
3 = Stage 3
4 = Auto
1 R/W COV
3
Analog
Value #3
Set Point Low
Limit to Set Point
High Limit
Set Point
This parameter is the
desired room
temperature value.
21 °C
(70 °F)
R/W COV
4
Analog
Value #4
5 °C to 40 °C
(41°F to 104°F)
Set Point
High Limit
This parameter adjusts
the high limit for
desired room
temperature.
30 °C
(86 °F)
R/W -
