TB7300 SERIES COMMUNICATING FAN COIL THERMOSTATS
13 62-2018—05
Mode button menu sequence.
• Modes presented to the user are dependent on sequence of operation selected.
• Default mode is in bold when sequence of operation parameter is changed.
Table 7. Auto Mode set to On = Auto system mode active.
Table 8. Auto Mode set to Off = Auto system mode NOT active.
Fan button menu sequences
Table 9. Available fan button menu sequences.
Auto speed fan mode is also offered in heating mode applications; it will not however have any effect on
dehumidification. It will be strictly for noise comfort issues
Auto Speed Fan Mode operation for sequences 2 and 3 is dependent on Auto Fan parameter. When Auto Fan is set to:
• AS (Default) = Auto Speed during occupied periods. Fan is always on during occupied periods. Low, medium and
high speeds operate on temperature offset from setpoint.
• AS AD = Auto Speed/Auto Demand during occupied periods.
— Medium and high speeds operate on temperature offset from setpoint.
— Low speed operates on demand and will shut down when no demand is present
Sequence selected Mode Menu
0 = Cooling only Off - Cool
1 = Heating only Off - Heat
2 = Cooling With Reheat Off – Auto – Heat – Cool
3 = Heating With Reheat Off - Heat
4 = Cooling/Heating 4 pipes Off – Auto – Heat – Cool
5 = Cooling/Heating 4 pipes with Reheat Off – Auto – Heat – Cool
Sequence selected Mode Menu
0 = Cooling only Off - Cool
1 = Heating only Off - Heat
2 = Cooling With Reheat Off – Heat – Cool
3 = Heating With Reheat Off - Heat
4 = Cooling/Heating 4 pipes Off – Heat – Cool
5 = Cooling/Heating 4 pipes with Reheat Off – Heat – Cool
Fan button menu
configuration
Menu presented are dependent on model used
and sequence of operation selected
Default value when
sequence toggled
0 Low-Med-High 3 Speed configuration using 3 fan relays (L-M-H) High
1 Low-High 2 Speed configuration using 2 fan relays (L-H) High
2 Low-Med-High-Auto 3 Speed configuration with Auto fan speed mode using 3 fan relays
(L-M-H)
High
3 Low-High-Auto 2 Speed configuration with Auto fan speed mode using 2 fan relays
(L-H)
High
4 On-Auto Single Speed configuration. Auto is for Fan on demand/On is On all
the time
Auto
