TB7300 SERIES COMMUNICATING FAN COIL THERMOSTATS
62-2018—05 18
DHumiLCK Dehumidification lockout
Default value = On =
Authorized
TB735xX5x14(x) models only
Typically toggled through the network.
This variable enables or disables dehumidification based on central
network requirements from the BAS front end.
On = Dehumidification Authorized
Off = Dehumidification Not Authorized
%RH set Dehumidification setpoint
Default value = 50% RH
TB735xX5x14(x) models only
Used only if dehumidification sequence is enabled:
Range is: 30-95% RH
DehuHyst Dehumidification Hysteresis
Default value = 5% RH
TB735xX5x14(x) models only
Humidity control hysteresis. Used only if dehumidification sequence
is enabled:
Range is: 2 to 20% RH
DehuCool Maximum Dehumidification
Cooling output
Default value = 100%
TB735xX5x14(x) models only
Maximum cooling valve position when dehumidification is enabled.
This can be used to balance smaller reheat loads installed in regards
to the capacity of the cooling coil.
Range is: 20 to 100%
St-By TM Stand-by Timer value
Default value = 0.5 hours
Time delay between the moment where the PIR cover detected the
last movement in the area and the time which the thermostat stand-
by mode and setpoints become active.
Range is: 0.5 to 24.0 hours in 0.5 hr increments
Unocc TM Unoccupied Timer value
Default value = 0.0 hours
Time delay between the moment where the thermostat toggles to
stand-by mode and the time which the thermostat unoccupied mode
and setpoints become active.
The factory value or 0.0 hours: Setting this parameter to its default
value of 0.0 hours disables the unoccupied timer. This prevents the
thermostat to drift from stand-by mode to unoccupied mode when
PIR functions are used
Range is: 0.0 to 24.0 hours in 0.5 hr increments
St-By HT Stand-by heating setpoint
Default value = 69 F
The value of this parameter should reside between the occupied and
unoccupied heating setpoints and make sure that the difference
between the stand-by and occupied value can be recovered in a
timely fashion when movement is detected in the zone.
Stand-by heating setpoint range is: 40 to 90 F (4.5 to 32.0 C)
St-By CL Stand-by cooling setpoint limit
Default value = 78 F
The value of this parameter should reside between the occupied and
unoccupied cooling setpoints and make sure that the difference
between the stand-by and occupied value can be recovered in a
timely fashion when movement is detected in the zone.
Stand-by cooling setpoint range is: 54 to 100 F (12.0 to 37.5 C)
Unocc HT Unoccupied heating setpoint
Default value = 62 F
Unoccupied heating setpoint range is: 40 to 90 F (4.5 to 32.0 C)
Unocc CL Unoccupied cooling setpoint
limit
Default value = 80 F
Unoccupied cooling setpoint range is: 54 to 100 F (12.0 to 37.5 C)
Heat max Maximum heating setpoint limit
Default value = 90 F (32 C)
Maximum occupied and unoccupied heating setpoint adjustment.
Heating setpoint range is: 40 to 90 F (4.5 to 32.0 C)
Cool min Minimum cooling setpoint limit
Default value = 54 F (12 C)
Minimum occupied and unoccupied cooling setpoint adjustment.
Cooling setpoint range is: 54 to 100 F (12.0 to 37.5 C)
Table 11. Configuration parameters
Configuration
parameters Default value Significance and adjustments
