Honeywell TrueEASE User Manual

WIRING
Wiring Conguration: Advanced Models (HE150/HE250/HE300)
Wiring Conguration: Basic Models (HE100/HE200)
Advanced Wiring Diagrams are shown in Appendix B
beginning on page 27.
Wiring HumidiPRO to TrueEASE Advanced Humidier with Fan Interlock (HE150/HE250/HE300).
Wiring HumidiPRO to TrueEASE Basic Humidier with Fan Interlock (HE100/HE200).
M34577
NOTE: SEE TrueEASE INSTALL GUIDE FOR DETAILED WIRING INFORMATION.
HumidiPRO
C
R
U
U
S
S
HVAC
GYWR C
THERMOSTAT
G “FAN”
24VAC
CONSTANT
POWER IN
NOT REQUIRED
ON HE300
OUTDOOR
SENSOR
M34570
1
TRANSFORMER
FURNACE
FAN
MOTOR
FAN CONTROL
L1
(HOT)
L2
POWER
SUPPLY
1
2
PROVIDE DISCONNECT MEANS AND
OVERLOAD PROTECTION AS REQUIRED.
24 VAC WIRING.
HUMIDIFIER
2
C
R
U
U
S
S
24 VAC (CONSTANT)
OUTDOOR SENSOR
Humidier 69-2413EF—09
17
