Honeywell TrueEASE User Manual

APPENDICES
Wiring TrueEASE to equipment with powered terminals.
Wiring Conguration: Basic Models (HE100/HE200)
M33039
HUMIDIFIER
WATER
SOLENOID
LEAD WIRE
COM
HUM
R
G
WIRING DIAGRAM ASSUMES THE USE OF EQUIPMENT-SPECIFIC
COMMUNICATING THERMOSTAT CONTROLLING THE HUMIDIFIER.
1
1
Wiring HumidiPRO with fan interlock.
M34570
1
TRANSFORMER
FURNACE
FAN
MOTOR
FAN CONTROL
L1
(HOT)
L2
POWER
SUPPLY
1
2
PROVIDE DISCONNECT MEANS AND
OVERLOAD PROTECTION AS REQUIRED.
24 VAC WIRING.
HUMIDIFIER
2
C
R
U
U
S
S
24 VAC (CONSTANT)
OUTDOOR SENSOR
Humidier 69-2413EF—09
29
