Wiring Conguration: Basic Models (HE100/HE200)
Wiring HumidiPRO in line with air proving device.
M34573
1
L1
(HOT)
L2
1 PROVIDE DISCONNECT MEANS AND OVERLOAD PROTECTION AS REQUIRED.
HUMIDIFIER
C
R
U
U
S
S
24 VAC (CONSTANT)
OUTDOOR SENSOR
AIR PRESSURE
SWITCH/SAIL
SWITCH
Humidier 69-2413EF—09
