Honeywell UDC3200 series - Mounting Procedures

04/08 UDC3200 Universal Digital Controller Operator Manual 7
2.4 Mounting
Physical Considerations
Overall Dimensions
Max. panel thickness
19,1
.75
Panel
Cutout
92,0 + 0,8
- 0,00
3,62 + 0,03
-0,00
92,0 + 0,8
- 0,00
3,62 + 0,03
-0,00
mm
inches
17,9
0,70
113,1
4,45
90,6
3,57
108,6
4,28
9,0
0,35
Figure 2-2 Mounting Dimensions (not to scale)
