V8200A,C,H,M AND VR8200A,C,H,M CONTINUOUS PILOT COMBINATION GAS CONTROLS
Automation and Control Solutions
Honeywell International Inc.
1985 Douglas Drive North
Golden Valley, MN 55422
Honeywell Limited-Honeywell Limitée
35 Dynamic Drive
Toronto, Ontario M1V 4Z9
customer.honeywell.com
® U.S. Registered Trademark
© 2011 Honeywell International Inc.
69-0422—03 M.S. Rev. 01-11
Printed in U.S.A.
If your gas supplier cannot be reached, call the
fire department.
Do not force the gas control knob on the
appliance. Use only your hand to push down the
reset button or turn the gas control knob. Never
use any tools. If the knob or reset button will not
operate by hand, the control should be replaced
by a qualified service technician. Force or
attempted repair may result in fire or explosion.
The gas control must be replaced if it has been
flooded with water. Call a qualified service
technician.
If the red reset button stays depressed after it is
released, the gas control should be replaced.
The gas control is a safety device. It must be
replaced in case of any physical damage such as
bent terminals, missing or broken parts, stripped
threads, or evidence of exposure to heat.
IMPORTANT
Follow the operating instructions provided by
the manufacturer of your heating appliance. The
information below will be of assistance in a
typical control application, but the specific
controls used and the procedures outlined by
the manufacturer of your appliance may differ,
requiring special instructions.
To Light The Pilot Burner
STOP: Read the safety information
above.
1. This appliance has a pilot burner which must be lit
by hand. If the pilot flame has gone out, follow
these instructions exactly.
2. Set thermostat to lowest setting and shut off elec-
tric power to appliance.
3. Remove burner access panel if provided on your
appliance.
4. Turn gas control knob (Fig. 4) clockwise to
OFF position.
5. Wait five minutes to allow any gas in the
combustion chamber to vent. If you then smell gas
in the appliance area or near the floor in an LP
installation, immediately shut off the manual valve
in the gas piping to the appliance or, WITH LP, AT
THE TANK. Don't touch any electrical switch or use
the phone. LEAVE THE BUILDING and call your
gas supplier. If your gas supplier cannot be
reached, call the fire department. Failure to do so
may result in fire or explosion.
6. If you don't smell gas, turn knob on gas control
counterclockwise to PILOT.
7. Push and hold down red reset button (Fig. 4) while
you light the pilot burner. Continue to hold the reset
button down for about one minute after the pilot is
lit. Release button; pilot should remain lit. If it goes
out, repeat steps 4-7. If the reset button does not
pop up when released, stop immediately and call
your service technician or gas supplier. If pilot will
not remain lit after several tries, turn gas control
knob to OFF and call your service technician or
gas supplier.
8. When pilot remains lit, turn gas control knob
counterclockwise to ON.
9. Replace burner access panel.
10. Turn on power.
11. Set thermostat to desired temperature.
To Turn Off Appliance
Vacation shutdown…turn gas control knob clockwise
from ON to PILOT. Pilot will remain lit, ready for
return to normal service without relighting.
Complete shutdown…turn gas control knob clockwise
to OFF. Both pilot and main burner are shut off. The
pilot must be manually relit when normal burner
operation is desired.
Tradeline
®
is a registered trademark of Honeywell Internatinal Inc.
Teflon™ is a trademark if E.I. DuPont De Nemous and Company.
