Xenon/Granit User Guide 319
Xenon B&W Scanner Guaranteed Performance
Xenon Color Scanner (Model COL) Typical Performance
Focus High Density (HD) Standard Range (SR) Extended Range (ER)
Symbology
Near
Distance
Far
Distance
Near
Distance
Far
Distance
Near
Distance
Far
Distance
5 mil Code 39 in. .3 3.3 2.1 5.1 4.2 7.8
mm 7.62 83.8 53.3 129.5 106.7 198.1
13 mil UPC in. .7 6.1 .4 15.6 1.1 19.7
mm 17.8 154.9 10.2 396.2 27.9 500.4
20 mil Code 39 in. .7 7.8 .5 20.2 1.5 25
mm 17.8 198.1 12.7 513.1 38.1 635
6.7 mil PDF417 in. .5 3.8 .9 5.8 3.3 8.7
mm 12.7 96.5 22.9 147.3 83.8 221
10 mil Data Matrix in. .4 3.8 .9 6.6 3.4 10.3
mm 10.2 96.5 22.9 167.6 86.4 261.6
20 mil QR Code in. 1.2 6.4 .7 13 .9 18
mm 30.5 162.6 17.8 330.2 22.9 457.2
Resolution (1D Code 39) 3 mil (.076mm) 5 mil (.127mm) 5 mil (.127mm)
Resolution (2D Data Matrix) 5 mil (.127mm) 6.7 mil (.170mm) 7.5 mil (.191mm)
Focus High Density (HD) Standard Range (SR)
Symbology
Near
Distance
Far Distance Near Distance Far Distance
5 mil Code 39 in. 0 3.6 1.1 5.2
mm 0 91.4 27.9 132.1
13 mil UPC in. .4 5.9 .4 16.2
mm 10.2 149.9 10.2 411.5
20 mil Code 39 in. .4 8.4 .5 22
mm 10.2 213.4 12.7 558.8
6.7 mil PDF417 in. 0 3.8 .4 6
mm 0 96.5 10.2 152.4
10 mil Data Matrix in. 0 4.2 .5 7
mm 0 106.7 12.7 177.8
20 mil QR Code in. .4 6.8 .6 13.4
mm 10.2 172.7 15.2 340.4
Resolution (1D Code 39) 3 mil (.076mm) 5 mil (.127mm)
Resolution (2D Data Matrix) 5 mil (.127mm) 6.7 mil (.170mm)
