3. To remove agitator, use a
screwdriver placed as shown.
5. If the end plates have
loosened, tighten them by
turning in opposite directions.
7. Slip plastic pulley end of
agitator through belt. (See
illustration.)
4. Use one hand to remove the
agitator as you use the end of
the screwdriver for leverage.
Remove old belt.
MOTOR
PULLEY
BELT
-
6. Place new belt over metal
motor pulley, with
lettering on
beit
visible and not against
pulleys.
AGITATOR
END
PlATk
8. Grasp a
itator firmly with
one hand.
Q
Be sure you can
see agitator end plate.) For
leverage, place screwdriver in
groove as shown.
17
