9. Lift and pull, using screw-
driver as a lever. Guide end
opposite belt into position first.
11. Press firmly to be sure
agitator is secure.
13. Maintaining front connec-
tion, rotate bottom
elate
to
covkr bottom of cleaner. Make
sure dirt duct is in position
under
elate.
Press firmlv.
10. Roll other side of agitator
into place.
12. The bottom plate attaches
in a hinge-like manner. Place
groove on front of bottom plate
over notched edge on front of
cleaner.
14. Lift and snap retaining
clips into place.
18
