Fully assemble product prior to use.
POSITION TOOLS
1. VACUUM ASSEMBLY
5
1.2 1.3
1.2 Insert handle section into vacuum base. Push
down firmly. Using a Phillips screwdriver, fasten (1) large
screw behind handle into vacuum base.
1.3 Wrap hose around top of hose guide located on the
handle. Insert the hose into hose tube until you hear
a click.
ATTACH DIRT CUP
1.6
1.6 Place bottom of dirt cup into vacuum body first.
Pivot cup into vacuum. Dirt cup is secure when you hear a
click.
1.4 Place Crevice Tool into the bottom of the extension
wand and slide onto the unit on the left back side (C) of
vacuum and place the Dusting Brush on right back side (E)
of vacuum as shown.
1.5 Place Pet Upholstery Tool*/ Pet Stair Tool* (F) on top of
the wand.
*Varies per model.
CARTON CONTENTS
Actual model may vary from images shown.
ATTACH HANDLE
1.5
E
F
C
1.4
A. Handle
B. Vacuum Base
C. Extension Wand
D. Crevice Tool*
E. Pet Upholstery Tool*
F. Dusting Brush*
G. (1) Large Screw
H. Dirt Cup
I. Pet Stair Tool*
J. Pet Turbo Tool*
*Varies per model.
Remove all parts from carton and identify
each item shown.
Make sure all parts are located before
disposing of packing materials.
1.1
A
B C G
H
E* F*D*
I*
J*
