Horotec FLASHTEST - Measuring Watch Operation Consumption

14
H. Mesurer la consommation d’une montre pendant son fonctionnement
H1. Appuyer sur la touche
CIRCUIT
du menu principal
FLASHTEST
pour mesurer la consommation de la montre.
The following screen displays :
H2a. Appuyer sur la touche
1.5V CONSUMPTION
du sous-menu
CIRCUIT
si la montre est alimentée en 1.5 V.
The following screen displays :
H2b. Appuyer sur la touche
3.0V CONSUMPTION
du sous-menu
CIRCUIT
si la montre est alimentée en 3.0 V.
The following screen displays :
Display of the sub-submenu
CIRCUIT
Display of the sub-submenu
1.5V CONSUMPTION
Display of the sub-submenu
3.0V CONSUMPTION
Use the probes and place them as shown on the sketch below.
- Measuring range : 0 … 19.999 μA
- Remove the battery
- PRESS THE WINDING STEM TO ACTIVATE ALL FUNCTIONS.
Caution : always choose the right polarity. NEVER CHOOSE the function 3.0 V for a 1.5 V watch.
Note : wait 5-10 seconds to get reliable results.
Compare the measured value to the one indicated in the manual. If the consumption is different than the one
stated by the manufacturer :
- The wheel trains are dirty or damaged which increases the friction of parts and the energy requirements of the
wheel trains.
Troubleshooting : clean, set up or change the wheel trains.
- The hands touch the dial or the watch crystal or they are loose.
Troubleshooting : adjust, clean or change the hands.
