Lubrication points (Lubrication grease: DIN 51825 KP/2K-40) - Number of lubrication points in brackets
Support wheels lubricate (2) 40 h
Undercarriage joint lubricate (2) 40 h
Parking brake lubricate (1) 40 h
Undercarriage bearing journal lubricate (4) 40 h
Support lubricate (1)
¾ Open the screw plug.
¾ Fill with approx. 200 g of special grease (high-performance EP
lubricating grease, lithium-saponied, with good adhesion and
corrosion properties and matching temperature range).
¾ Close the screw plug.
First after
3 years,
than yearly
Bolt wing mounting lubricate (4) 40 h
Drawbar eye Lubricate contact areas in the coupling point as required
Lubrication points with the addition "2x" can be found on either side of the machine.
2x
2x
72
