SPA LOCK
When activated, the Spa Lock
feature disables all functions on the
control panel. It prevents others from
tampering with the jets, lights and
temperature settings on your spa. The
control panel will not respond to any
hard or soft buttons when pushed in
Spa Lock mode.
To activate the Spa Lock:
• Press the OPTIONS hard button.
• Press the soft button next to Set-up.
• Press the soft button next to Spa Lock Off.
IMPORTANT: The Temperature/Spa Lock icon will be displayed while
the screens are locked.
To deactivate the Spa Lock:
• Press and hold the OPTIONS hard button and the LIGHTS hard button
at the same time for 3 seconds. The spa lock icon will turn off.
IMPORTANT: You can activate the spa lock feature even when
the temperature lock is already on. You do not need to turn off the
temperature lock in order to turn on the spa lock feature. If the
temperature lock was already on when you activate the spa lock, it
will remain on when you turn off the spa lock.
JETS CONTROL
The JETS hard button activates the jet
pumps. When the JETS hard button is
pressed, the jets menu will be displayed
on the control panel with Jet 1 in the
Low position
, the Jet Pump icon will
also display on the home screen. Press
any of the soft keys to change the jet
functions between high or low (when
available) speed, and off.
The GLEAM model has 3 jet pumps, Jet 3 can be found in the lower
right corner for GLEAM spas only. The third jet pump can only be
activated by pressing the soft key next to Jet 3.
The jets icon (on the Home Screen) will remain lit until the button is
pressed to turn off the jet pump(s), or after two hours of continuous
operation when the pump(s) is automatically shut off by the control
system.
The jet pump(s) will turn themselves off after two hours of continuous operation
to prevent overheating and conserve energy in case you forgot they were on.
The jets can be restarted again with no delay.
IMPORTANT: The jet pumps will not function while the spa lock feature
is activated.
You may also run through the entire jet pump cycle by only using the
JETS hard button as follows:
GLEAM , PULSE, FLAIR & GLOW
1st Press = Jet pump 1 on Low 2nd Press = Jet pump 1 on High
3rd Press = Both jet pumps on
high speed
4th Press = Jet pump 1 on
Low, Jet pump 2 on high
5th Press = Jet pump 2 on High 6th Press = All pumps off
BOLT
1st press = jet pump on High 2nd press = jet pump OFF
LIGHT CONTROL
All HOT SPRING spas are equipped with Multi-Color lighting.
Press the LIGHTS hard button to activate the Interior Lights and display
the screen.
To change the intensity of the spa’s Interior lights:
• Press the soft button next to Dimmer.
There are three (3) brightness levels
plus off.
IMPORTANT: Pressing the LIGHTS
hard button several times will also
change the intensity of the spa's
Interior lights when in the Interior
Lights screen from brightest to off,
back to brightest.
To change the color of the Interior lights:
• Press the soft button next to Color.
The colors are as follows: 1) Blue, 2) Aqua, 3) Green, 4) White, 5)
Yellow, 6) Red, 7) Magenta, 8) Color Wheel On, 9) Color Wheel Off.
NOTE: Lights icon on the Home Scree will flash whenever the Color
Wheel is on.
To turn off all of the lights:
• Press the soft button next to Lights Off.
GLEAM Spa Only:
The Gleam spa has exterior lights.
IMPORTANT: Pressing the LIGHTS
hard button will turn on both the Interior
and Exterior lights. Pressing the hard
light button a second time will dim
interior to 2, press hard light button a
third time will dim interior to 1, press
hard light button a fourth time will dim
interior to off, press the hard light button a fifth time will shut all lights off.
• Press the soft button next to Exterior Lighs to view the Exterior Lights
screen.
• Press the soft button next to Daily
Lights to turn on the 24 hour external
light time. Activating the timer will turn
external lights on for 6 hours at the
same time every day.
• Press the soft button next to Daily
Lights a second time to turn the timer
Off
• Press the soft button next to Interior Lights to return to the Interior
Lights menu.
SUMMER TIMER
Your HOT SPRING spa is equipped with a summer timer. The summer
timer can be activated during extremely hot summer months to
maintain water temperatures. Activating the summer timer causes the
heater to immediately shut down. The circulation pump will remain
on for approximately 5 minutes pushing water through the heater to
cool it down. Both heater and circulation pump will then remain off for
eight hours. The summer time icon will be displayed on the control
Page 15
Operating Instructions
