Hotsy 795SS - Exploded View Parts List (Items 60-76)

8.914-355.0 • Rev. 07/17
19
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
60 8.715-555.0 Pulley, 2AK 64 H 1
(790SS)
8.715-573.0 Pulley, BK 85H 1
(795SS, 795SS-208)
8.715-591.0 Pulley, 2BK 70H 1
(895SS)
61 9.802-402.0 Bushing, H x 24mm 1
62 9.800-049.0 Label, Manufacturers 1
Cleaning Solution
63 8.718-582.0 Bolt, 1/4-20 x 1/2", Nc Hh 2
64 8.706-577.0 Trim, Edge Guard, Blk/Ft 1
65 8.706-731.0 Bushing, 3/4" Snap 1
66 8.752-969.0 Strain Relief, 1/2 NPT
(790SS Only) 1
9.802-518.0 Strain Relief, 3/4 Npt.49-.71D 1
(895SS, 795SS, 795SS-208)
68 9.802-767.0 Screw, 3/8" x 3/4" Nc, 4
Whiz Loc Flange (895SS)
9.803-277.0 Screw, 5/16" x 1/2", Whiz 4
Loc Flange
(795SS, 795SS-208)
69 8.719-047.0 Washer, Nylon, 4
.281 Id x 1 Od x .25 Thk
(895SS Only)
70 8.901-144.0 Label, Hotsy, Logo 1
71 9.802-819.0 WASHER, 7/16" x 2 1/2", ZINC, PG
FOOT 3
72 9.802-710.0 Screw 5/16" x 1"NC 3
73 9.800-034.0 Label, Clear Lexan, 1
4.3" x 5.5"
74 8.930-124.0 Label, Intended for outdoor 1
Use - Mexico
75 8.754-337.0 Label, ETL (RL1500),
UL STD 1776, CERT 1
76 8.918-424.0 Hose, 3/8" x 25", 2 Wire 1
1 Press Loop (Only 895SS)
