Hotsy 795SS - Pump Exploded View Parts List (Cont.)

8.914-355.0 • Rev. 07/17
29
PRESSURE WASHER
OPERATOR’S MANUAL
PUMP - EXPLODED VIEW PARTS LIST
KIT NUMBER
8.754-856.0 8.754-857.0 8.754-858.0 8.754-859.0 9.803-937.0
KIT DESCRIPTION
Plunger
Seals 16
mm
Seal Pack-
ing 16 mm
Plunger 16
mm
Complete
Valve
Plunger Oil
Seals
ITEM NO.'S INCLUDED 4, 6, 8 4, 5, 6, 7, 8
36, 37, 38,
39
12, 13, 14 3
NUMBER OF CYL-
INDERS KIT WILL
SERVICE
3 1 1 6 3
ITEM PART NO. DESCRIPTION QTY
27 8.717-137.0 Bearing Cover 2
28 9.803-954.0 Bearing Seal 1
29 8.754-843.0 Seal Spacer, Crankshaft 2
30 9.802-914.0 Snap Ring, 25 mm 1
31 9.803-955.0 Bearing, Ball 2
32 8.754-830.0 Shaft, 24 mm 4025 1
33 9.803-167.0 Key, Crankshaft 1
34 8.754-219.0 Oil Dipstick 1
35 8.933-010.0 Seal, Crankshaft 1
36* 8.754-855.0 Bolt, Plunger 3
37* 8.754-092.0 Spacer, Copper 3
38* 8.754-848.0 Plunger, 16 mm 3
39* 9.803-962.0 Spacer, Copper 3
40 8.754-827.0 Plunger Rod 3
41 9.803-965.0 Connecting Rod Pin 3
42 9.803-966.0 Connecting Rod 3
43 9.803-218.0 Washer, 6 mm 6
44 8.933-020.0 Screw, Connecting Rod 6
45 8.754-847.0 O-ring Ø2.62 X 111.62 1
46 8.754-842.0 Cover, Crankcase 1
47 9.803-906.0 O-ring Ø1.78 X 14 1
48 9.803-202.0 Sight Glass, G3/4 1
* Available in kit (See below)
