Hotsy 982SS - Exploded View Parts List

97-6574 • HOTSY 900-1400 GAS FIRED • REV. 10/05
OPERATOR’S MANUAL
PRESSURE WASHER
22
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 213034 Tob Hat, Weld Assy., 18” Hotsy Coil 1
2 873749 Insulation, Top Head, 18 OD x 1.8 ID, Fiberglass 1
3 860102 Ring, Insulation Retainer, 16” Top Hat 1
4 824115 Clip, Retaining U-Type 2
5 241098 Coil, Service Gas 900/1000 1
6 722417 Insulation, 30.75 x 59, Fiberglass 1
7 375513 Coil, SS, Tank, Weldment 1
8 861644 Hanger, Hose 1
9 914903 Label, Plate AL Hotsy 2
10 926598 Rivet, 1/8” x 1/4”, POP, AL 8
11 2-0008 Nipple, 1/2” Hex Steel 2
12 2-0052 Nipple, 1/2” JIC, 1/2” Pipe 1
13 2-0028 Elbow, 1/2”, 90° Female Pipe 1
14 2-00681 Bushing, 1/2” x 3/8”, Steel 1
15 2-10999 Block, Coil Discharge 1
16 2-00494 Plug, 1/2” Countersunk 1
17 2-3409 Rupture Disc Assy., 7000# 1
18 2-1019 Elbow, 3/8” Female, Brass 1
19 2-10862 Hose Barb, 3/8” Barb x 3/8” ML Pipe 1
20 4-02120003 Hose, 3/8” Push-On 45”
21 6-01271 Conduit, Flexo, Black 42”
22 95-07104320 Frame, Welded Assembly, Gas 1
23 95-07104307 Panel, 900/1400 Side 1
24 2-010381 Grommet, 2-1/8” x 2-7/8” x 7/16” Rubber 1
25 90-1000 Bolt, 1/4” x 1/2”, NC HH 17
26 90-4000 Washer, 1/4” Flat, SAE 23
27 2-01403 Bushing, 5/8” Snap 6
28 95-0710375584 Slider, Pump, Weldment 1
29 90-2001 Nut, 5/16” ESNA, NC 8
30 90-4001 Washer, 5/16” Flat, SAE 8
31 90-102746 Bolt, 1/2” x 5” NC HH Tap, All Thread 1
32 90-3096 Washer, 1/2” Flat, SAE 1
33 2-01401 Bushing, 1-3/8” Snap 1
34 95-07104306 Panel, Long Frame Cover 1
35 95-07104305 Panel, Small Frame Cover 1
36 90-2002 Nut, 3/8” ESNA, NC 4
37 90-4002 Washer, 3/8” SAE, Flat 12
38 90-4006 Washer, 5/16” x 1-1/4” Fender, SAE 4
39 90-1016 Bolt, 3/8” x 1” NC HH 4
40 95-07104308 Panel, Back Welded Assy. 1
41 95-07104330 Bracket, Unloader 1
42 95-07104301 Panel, Front 1
43 Motor, Please See Specifications Page
44 5-604040 Belt, BX40 2
45 Pump Pulley, Please See Specifications Page
