97-6574 • HOTSY 900-1400 GAS FIRED • REV. 10/05
23
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
46 Motor Pulley, Please See Specifications Page
47 5-5120220 Bushing, H x 22mm 1
48 Motor Bushing, Please See Specifications Page
49 95-07104313 Cover, Back Panel 1
50 95-07104309 Cover, Cabinet 1
51 2-9013 Clamp, 1/2” 1
52 2-00601 Elbow, 1/2” JIC x 3/8” Female, 90° 1
53 90-29980 Screw, #8 x 1/2”, Phillips, Zinc 2
54 11-10480 Label, Warning 1
55 11-0510 Label, Hotsy 900/1400 Control Panel 1
56 90-10343 Bolt, 10mm x 20mm, HH 4
57 90-1001 Bolt, 1/4” x 3/4” NC HH 4
58 90-2000 Nut, 1/4” ESNA, NC 4
59 4-02047727 Hose, 3/8” 2 Wire Pressure Loop 27”
60 90-100461 Screw, 1/4-20 x 1/2” Tri-Round, Black, Zinc 12
61 10-01002 Label, Natural Gas 1
10-01001 Label, LP (LP Option) 1
62 2-010381 Grommet, Rubber 1
63 6-051595 Strain Relief 1
64 6-0105 Cord, Service, 12/4 (962SS, 962SS-208,
992SS, 964SS, 969SS, 991SS, 991SS-208,
992SS-208. 994SS, 995SS, 1424SS, 1425SS,
1464SS, 1469SS) 45”
6-0108 Cord, Service, 10/3 (952SS, 952SS-208,
982SS, 981SS) 45”
6-0109 Cord, Service, 10/4 (1462SS, 1422SS-208,
1422SS, 1421SS-208, 1421SS, 1462SS-208) 45”
6-0102 Cord, Service, 8/3 (1411SS, 1412SS, 1452SS,
1452SS-208) 45”
65 2-0103 Grommet, Rubber, 1
66 10-09004 Label, Hot Water 1
67 95-07104328 Cover, Electrical Box 1
68 10-08021 Label, Disconnect Power Supply 1
69 90-1981 Screw, 4mm x 4mm, Panhead 1
70 2-2007 Nipple, 3/8” x 3/8” NPT 1
71 10-09003 Label, Cold Water Inlet 1
72 90-1006 Bolt, 5/16” x 3/4” NC, Grade 5 4
73 10-02028 Label, Exposed Label 2
74 9.800-049.0 Label, Detergent Warning 1
75 90-1808 Screw, 10/32” x 5/8” Phil Pan SS 1
76 90-017 Nut, 10/32” KEPS 1
77 95-07104337 Bracket, Transformer (969SS, 1469SS) 1
78 90-1007 Bolt, 5/16” x 1” NC, HH (969SS, 1469SS) 2
79 90-2001 Nut, 5/16” ESNA, NC (969SS, 1469SS) 2
80 90-4001 Washer, 5/16” Flat, SAE (969SS, 1469SS) 2
To Next Page
