4 Options
4.1 Drive
The wheels are driven by a worm gear or a spur-gear drive
motor using a v-belt; the type and size of the motor depends
on the wheel diameter:
■ Drive Y
for direct drive by mains power. On/Off operation at
constant speed only.
■ Drive A
The motor speed and therefore the performance of the
rotary heat exchanger can be controlled. A control unit
(option R) is required.
Motor designation A 60 A 250 A 370 A 750
Motor power kW 0.06 0.25 0.37 0.75
Output shaft mm 18 x 34 20 x 55 20 x 65 25 x 60
Current Y (direct operation by mains power) A 0.25 0.83 1.09 1.92
Current Δ (with control unit) A 0.30 1.44 1.90 3.40
Protection rating Drive Y – IP 44 IP 55 IP 55 IP 55
Drive A – IP 54 IP 55 IP 55 IP 55
Motor nominal speed n
1
min
-1
1600 1320 1380 1400
Output speed n
2
at 50 Hz min
-1
100 132 138 140
Motor nominal torque m
1
Nm 0.5 1.81 2.60 5.10
Output torque m
2
Nm 6.1 14 21 45
Rotor diameter mm up to 1300 up to 1800 up to 2620 up to 3800
Control unit Type R / 370 R / 370 R / 370 R / 750
Table 2: Data sheet for rotary drives
