ASSEMBLY
2.6 Mounting the thermal insulation Max-3 plus (1500-2700) 1. Wrap the insulating mats (1/1a, Fig. 17) around the boiler body (joint at the side, black side outwards). 2. Secure insulating mats (1) with plastic straps (2) and strap fasteners (2a):
-
- do not overtighten the straps (reduced insulating value)
3.
the rear casing panel (14,15,16, Fig. 21).
4. Place insulating mat (4, Fig. 17) on the pins welded to the rear wall of the boiler and secure with the retaining discs (Fig. 16). 5. Place insulating plates (5/5a/5b/5c, Fig. 17) on the pins moulded to the front wall of the boiler and secure with the retaining discs (Fig. 16). 6.
