9.3. Heating / cooling change-over
If an input is allocated for switching over between heating and cooling, one each of the two functions is blocked
and the other is enabled:
Input open: Heating requirement function is active. Cooling requirement is blocked.
If the input is closed: Heating requirement function is blocked. Cooling requirement is active.
9.4. Temperature requirement menu
Parameter
Designation
Value
Min.
Max.
Comment
R
W
07-002
Min. requirement heating
5 °C
0.0
100.0
Min. requirement heating
3
3
07-008
Max. requirement heating
100 °C
0.0
120.0
Max. requirement heating
3
3
07-035
Heating requirement type
1=Heat generator
Heating requirement type
3
3
30-063
Allocation heating
requirement input
0=OFF
Allocation heating
requirement input
3
3
06-113
Characteristic curve X1
heating
0.5 V
0.0
10.0
Characteristic curve X1
heating
3
3
06-111
Characteristic curve Y1
heating
5 °C
0.0
100.0
Characteristic curve Y1
heating
3
3
06-114
Characteristic curve X2
heating
10 V
0.0
10.0
Characteristic curve X2
heating
3
3
06-112
Characteristic curve Y2
heating
100 °C
0.0
120.0
Characteristic curve Y2
heating
3
3
07-114
Min. requirement cooling
5 °C
0.0
100.0
Min. requirement cooling
3
3
07-115
Max. requirement cooling
100 °C
0.0
120.0
Max. requirement cooling
3
3
07-059
Cooling requirement type
1=Heat generator
Cooling requirement type
3
3
30-064
Allocation cooling
requirement input
0=OFF
Allocation cooling
requirement input
3
3
06-117
Characteristic curve X1
cooling
0.5 V
0.0
10.0
Characteristic curve X1
cooling
3
3
06-115
Characteristic curve Y1
cooling
5 °C
0.0
100.0
Characteristic curve Y1
cooling
3
3
06-118
Characteristic curve X2
cooling
10 V
0.0
10.0
Characteristic curve X2
cooling
3
3
06-116
Characteristic curve Y2
cooling
100 °C
0.0
120.0
Characteristic curve Y2
cooling
3
3
36-004
Min. requirement hot water
5 °C
0.0
100.0
Min. requirement hot water
3
3
05-057
Max. requirement hot water
100 °C
0.0
120.0
Max. requirement hot water
3
3
05-087
Hot water requirement type
1=Heat generator
Hot water requirement type
3
3
30-065
Allocation hot water req. input
0=OFF
Allocation hot water req. input
3
3
36-002
Characteristic curve X1 hot
water
0.5 V
0.0
10.0
Characteristic curve X1 hot
water
3
3
36-000
Characteristic curve Y1 hot
water
5 °C
0.0
100.0
Characteristic curve Y1 hot
water
3
3
36-001
Characteristic curve X2 hot
water
10 V
0.0
10.0
Characteristic curve X2 hot
water
3
3
36-003
Characteristic curve Y2 hot
water
100 °C
0.0
120.0
Characteristic curve Y2 hot
water
3
3
