12. Information sensor / information 0-10V
12.1. Information sensor
Various inputs can be used as information values in the Info values menu.
Variant 1: Information sensor temperature
5 Temperature inputs can be defined as information sensors. Individual designations/names can be defined for
each of these information sensors. The input is not monitored for interruption and short circuit. The description
below relates to the first information sensor.
Information sensor temperature 1
Input allocation information sensor 1
Name information sensor 1
General
information/
info values
… type of sensor
0=KTY, 1=PTC, 2=PT1000
12.2. Information 0-10V
Variant 2: Information 0-10V:
3 information values 0-10V can be defined. Individual designations/names can be defined for each of these
information values. The value is shown without unit. If a unit is required, this must be put in the freely selectable
designation/name.
The voltage applied to the input is converted with a linear characteristic and displayed. The characteristic passes
through the zero point (0 volt = displayed value 0) and through the point (10V, parameter "conversion for 10V").
The description below relates to the first 0-10V information value.
Input allocation information 1 0-10V
0=OFF, 4=VE10V, 10=VE10V-FE1, 16=VE10VFE2
General
information/
info values
Example: oil level gauge 0V= 0 ltr., 10V = 5000 ltr. (TTE-PS VE10V)
30-076 : 4 (alloc. inp. VE10V)
20-100 : 500 (conversion factor, 10 x 500 = 5000 at 10V)
20-095 : ltr. oil level (designation/name)
